Ordoñezite
A valid IMA mineral species - grandfathered
This page is currently not sponsored. Click here to sponsor this page.
About Ordoñezite
Ezequiel Ordoñez
Formula:
ZnSb2O6
Colour:
Very light to very dark brown, variable from colorless to pearl gray, olive buff to dark olive, light yellowish olive, bone brown (Ridgeway), transparent.
Lustre:
Adamantine
Hardness:
6½
Specific Gravity:
6.635
Crystal System:
Tetragonal
Member of:
Name:
Named in 1955 by George Switzer and William Frederick Foshag in honor of Ezequiel Ordoñez [April 10, 1867 San Nicolás Peralta, Lierma, Mexico, Mexico - February 8, 1950 Mexico City, Mexico], professor of mineralogy and geology at the Escuela Nacional Preparatoria, where he also worked on the geologic map of Mexico published in 1889. Ordoñez became an expert in petroleum geology and greatly influenced the development of petroleum extraction. Ordoñez was eventually appointed head of the Instituto de Geología de Mexico.
This page provides mineralogical data about Ordoñezite.
Unique Identifiers
Mindat ID:
3014
Long-form identifier:
mindat:1:1:3014:0
IMA Classification of Ordoñezite
Approved, 'Grandfathered' (first described prior to 1959)
IMA Formula:
ZnSb5+2O6
First published:
1955
Classification of Ordoñezite
4.DB.10
4 : OXIDES (Hydroxides, V[5,6] vanadates, arsenites, antimonites, bismuthites, sulfites, selenites, tellurites, iodates)
D : Metal: Oxygen = 1:2 and similar
B : With medium-sized cations; chains of edge-sharing octahedra
4 : OXIDES (Hydroxides, V[5,6] vanadates, arsenites, antimonites, bismuthites, sulfites, selenites, tellurites, iodates)
D : Metal: Oxygen = 1:2 and similar
B : With medium-sized cations; chains of edge-sharing octahedra
44.2.1.2
44 : ANTIMONATES
2 : AX2O6
44 : ANTIMONATES
2 : AX2O6
24.2.4
24 : Antimonates and Antimonites
2 : Antimonates of Be, Mg, Ca, Zn or Hg
24 : Antimonates and Antimonites
2 : Antimonates of Be, Mg, Ca, Zn or Hg
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference |
|---|---|---|
| Ord | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Physical Properties of Ordoñezite
Adamantine
Transparency:
Transparent
Colour:
Very light to very dark brown, variable from colorless to pearl gray, olive buff to dark olive, light yellowish olive, bone brown (Ridgeway), transparent.
Hardness:
6½ on Mohs scale
Cleavage:
None Observed
Fracture:
Conchoidal
Density:
6.635 g/cm3 (Measured) 6.657 g/cm3 (Calculated)
Optical Data of Ordoñezite
Type:
Uniaxial (+)
Reflectivity:
| Wavelength | R1 (%) | R2 (%) |
|---|---|---|
| 470nm | 19.9% | 18.6% |
| 546nm | 16.8% | 16.3% |
| 589nm | 17.0% | 16.5% |
| 650nm | 16.9% | 16.3% |
Graph shows reflectance levels at different wavelengths (in nm). Peak reflectance is 19.9%.
R1 shown in black, R2 shown in red
Comments:
RI > 2.3
Chemistry of Ordoñezite
Mindat Formula:
ZnSb2O6
Element Weights:
Elements listed:
Common Impurities:
Al,Si
Crystallography of Ordoñezite
Crystal System:
Tetragonal
Class (H-M):
4/mmm (4/m 2/m 2/m) - Ditetragonal Dipyramidal
Space Group:
P42/mnm
Setting:
P42/mnm
Cell Parameters:
a = 4.6638(4) Å, c = 9.263(1) Å
Ratio:
a:c = 1 : 1.986
Unit Cell V:
201.48 ų (Calculated from Unit Cell)
Morphology:
Drusy or stalactitic masses of repeatedly twinned tetragonal crystals having a maximum size of 2 mm.
Twinning:
Twin plane (013)
Crystallographic forms of Ordoñezite
Crystal Atlas:
Image Loading
Click on an icon to view
Ordoñezite - {011}, {001}, {100}
3d models and HTML5 code kindly provided by
www.smorf.nl.
Toggle
Edge Lines | Miller Indices | Axes
Transparency
Opaque | Translucent | Transparent
View
Along a-axis | Along b-axis | Along c-axis | Start rotation | Stop rotation
Toggle
Edge Lines | Miller Indices | Axes
Transparency
Opaque | Translucent | Transparent
View
Along a-axis | Along b-axis | Along c-axis | Start rotation | Stop rotation
X-Ray Powder Diffraction
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 4.170 Å | (37) |
| 3.303 Å | (93) |
| 2.578 Å | (97) |
| 2.334 Å | (51) |
| 1`.730 Å | (100) |
| 1.651 Å | (52) |
| 1.476 Å | (50) |
| 1.399 Å | (64) |
| 1.390 Å | (60) |
| 1.288 Å | (37) |
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| Stage 7: Great Oxidation Event | <2.4 |
| 47d : [Arsenates, antimonates, selenates, bismuthinates] | |
| 47h : [Near-surface oxidized, dehydrated minerals] |
Type Occurrence of Ordoñezite
General Appearance of Type Material:
small crystals
Place of Conservation of Type Material:
The Natural History Museum, London, England, 1965,208.
Harvard University, Cambridge, Massachusetts, 110282.
National Museum of Natural History, Washington, D.C., USA, R9127.
Harvard University, Cambridge, Massachusetts, 110282.
National Museum of Natural History, Washington, D.C., USA, R9127.
Geological Setting of Type Material:
Cassiterite bearing veins in rhyolite.
Associated Minerals at Type Locality:
Other Language Names for Ordoñezite
Relationship of Ordoñezite to other Species
Member of:
Other Members of Byströmite Group:
| Byströmite | MgSb2O6 | Tet. 4/mmm (4/m 2/m 2/m) : P4/nmm |
| Tredouxite | NiSb2O6 | Tet. 4/mmm (4/m 2/m 2/m) : P42/mnm |
Common Associates
Associated Minerals Based on Photo Data:
| 5 photos of Ordoñezite associated with Chenevixite | Cu2Fe3+2(AsO4)2(OH)4 |
| 5 photos of Ordoñezite associated with Zapatalite | Cu3Al4(PO4)3(OH)9 · 4H2O |
| 1 photo of Ordoñezite associated with Quartz | SiO2 |
| 1 photo of Ordoñezite associated with Oxyplumboroméite | Pb2Sb2O6O |
Related Minerals - Strunz-mindat Grouping
| 4.DB. | Nioboheftetjernite | ScNbO4 |
| 4.DB. | Nioboixiolite-(Mn2+) | (Nb0.67Mn2+0.33)O2 |
| 4.DB. | Shakhdaraite-(Y) | ScYNb2O8 |
| 4.DB.05 | Varlamoffite | Sn1-xFexO2-x(OH) |
| 4.DB.05 | Argutite | GeO2 |
| 4.DB.05 | Cassiterite | SnO2 |
| 4.DB.05 | Rutile | TiO2 |
| 4.DB.05 | Plattnerite | PbO2 |
| 4.DB.05 | Tripuhyite | Fe3+Sb5+O4 |
| 4.DB.05 | Tugarinovite | MoO2 |
| 4.DB.05 | Pyrolusite | Mn4+O2 |
| 4.DB.10 | Byströmite | MgSb2O6 |
| 4.DB.10 | Tredouxite | NiSb2O6 |
| 4.DB.10 | Tapiolite-(Mn) | Mn2+Ta2O6 |
| 4.DB.10 | Tapiolite-(Fe) | Fe2+Ta2O6 |
| 4.DB.15a | Paramontroseite | V4+O2 |
| 4.DB.15a | Ramsdellite | Mn4+O2 |
| 4.DB.15b | Akhtenskite | ε-Mn4+O2 |
| 4.DB.15c | Nsutite | (Mn4+,Mn2+)(O,OH)2 |
| 4.DB.20 | Scrutinyite | α-PbO2 |
| 4.DB.20 | Nioboixiolite-([]) | (Nb0.8◻0.2)4+O2 |
| 4.DB.25 | Ishikawaite | U4+Fe2+Nb2O8 |
| 4.DB.25 | Yttrocolumbite-(Y) | Y(U4+,Fe2+)Nb2O8 |
| 4.DB.25 | Calciosamarskite | (Ca,U4+)Fe3+(Nb,Ta,Ti)2O8 |
| 4.DB.25 | Samarskite-(Yb) | YbFe3+(Nb,Ta)2O8 |
| 4.DB.25 | Ixiolite-(Fe2+) | (Ta0.67Fe2+0.33)O2 |
| 4.DB.25 | Ixiolite-(Mn2+) | (Ta0.67Mn2+0.33)O2 |
| 4.DB.25 | Srilankite | ZrTi2O6 |
| 4.DB.25 | Samarskite-(Y) | YFe3+Nb2O8 |
| 4.DB.25 | Nioboixiolite-(Fe3+) | (Nb0.5Fe3+0.5)O2 |
| 4.DB.30 va | Wolframite Group | |
| 4.DB.30 | Rossovskyite | (Fe3+,Ta)(Nb,Ti)O4 |
| 4.DB.30 | Huanzalaite | MgWO4 |
| 4.DB.30 | Heftetjernite | ScTaO4 |
| 4.DB.30 | Hübnerite | MnWO4 |
| 4.DB.30 | Sanmartinite | (Zn,Fe)WO4 |
| 4.DB.30 | Ferberite | FeWO4 |
| 4.DB.30 | Krasnoselskite | CoWO4 |
| 4.DB.35 | Qitianlingite | (Fe,Mn)2(Nb,Ta)2WO10 |
| 4.DB.35 | Tantalaeschynite-(Ce) | Ce(TiTa)O6 |
| 4.DB.35 | Tantalite-(Mg) | (Mg,Fe2+)(Ta,Nb)2O6 |
| 4.DB.35 | Columbite-(Mn) | Mn2+Nb2O6 |
| 4.DB.35 | Tantalite-(Mn) | Mn2+Ta2O6 |
| 4.DB.35 | Columbite-(Fe) | Fe2+Nb2O6 |
| 4.DB.35 | Columbite-(Mg) | (Mg,Fe,Mn)(Nb,Ta)2O6 |
| 4.DB.35 | Tantalite-(Fe) | Fe2+Ta2O6 |
| 4.DB.40 | Ferrotitanowodginite | Fe2+TiTa2O8 |
| 4.DB.40 | Wolframowodginite | Mn(Mn,Sn,Fe,Ta)(W,Ta,Nb)2O8 |
| 4.DB.40 | Lithiotantite | LiTa3O8 |
| 4.DB.40 | Lithiowodginite | LiTa3O8 |
| 4.DB.40 | Titanowodginite | Mn2+TiTa2O8 |
| 4.DB.40 | Tantalowodginite | (Mn2+0.5◻0.5)TaTa2O8 |
| 4.DB.40 | Wodginite | Mn2+Sn4+Ta2O8 |
| 4.DB.40 | Ferrowodginite | Fe2+Sn4+Ta2O8 |
| 4.DB.45 | Tivanite | V3+TiO3(OH) |
| 4.DB.50 | Carmichaelite | (Ti,Cr,Fe)[O2-x(OH)x] |
| 4.DB.55 | Alumotantite | AlTaO4 |
| 4.DB.60 | Biehlite | ((Sb,As)O)2[MoO4] |
Other Information
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for Ordoñezite
mindat.org URL:
https://www.mindat.org/min-3014.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
References for Ordoñezite
Localities for Ordoñezite
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
Canada | |
| Josef Vajdak (2008) |
Germany | |
| Schnorrer-Köhler (1986) +1 other reference |
Italy | |
| Batacchi et al. (2011) |
Mexico | |
| Can Min 40 et al. (2002) |
| Am Min (1955) +1 other reference |
| ... |
| RRUFF project |
Spain | |
| Georges FAVREAU collection and EDX ... |
Switzerland | |
| Schmutz et al. (1986) +1 other reference |
| Schmutz et al. (1986) | |
USA | |
| Northrop et al. (1996) |
