Tainiolite
A valid IMA mineral species - grandfathered
This page is currently not sponsored. Click here to sponsor this page.
About Tainiolite
Formula:
KLiMg2(Si4O10)F2
Colour:
Colourless, brownish green
Lustre:
Vitreous, Silky
Hardness:
2½ - 3½
Specific Gravity:
2.83 - 2.90
Crystal System:
Monoclinic
Member of:
Name:
From Greek "tainia", ribbon, alluding to the tabular habit of its crystals.
Unique Identifiers
Mindat ID:
7325
Long-form identifier:
mindat:1:1:7325:3
IMA Classification of Tainiolite
Approved, 'Grandfathered' (first described prior to 1959)
IMA Formula:
KLiMg2Si4O10F2
Type description reference:
Classification of Tainiolite
9.EC.15
9 : SILICATES (Germanates)
E : Phyllosilicates
C : Phyllosilicates with mica sheets, composed of tetrahedral and octahedral nets
9 : SILICATES (Germanates)
E : Phyllosilicates
C : Phyllosilicates with mica sheets, composed of tetrahedral and octahedral nets
71.2.2b.9
71 : PHYLLOSILICATES Sheets of Six-Membered Rings
2 : Sheets of 6-membered rings with 2:1 layers
71 : PHYLLOSILICATES Sheets of Six-Membered Rings
2 : Sheets of 6-membered rings with 2:1 layers
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
Please only use the official IMA–CNMNC symbol. Older variants are listed for historical use only.
Please only use the official IMA–CNMNC symbol. Older variants are listed for historical use only.
| Symbol | Source | Reference |
|---|---|---|
| Tai | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
| Tai | The Canadian Mineralogist (2019) | The Canadian Mineralogist (2019) The Canadian Mineralogist list of symbols for rock- and ore-forming minerals (December 30, 2019). download |
| Tai | Warr (2020) | Warr, L.N. (2020) Recommended abbreviations for the names of clay minerals and associated phases. Clay Minerals, 55, 261–264 doi:10.1180/clm.2020.30 |
Physical Properties of Tainiolite
Vitreous, Silky
Transparency:
Transparent
Colour:
Colourless, brownish green
Hardness:
2½ - 3½ on Mohs scale
Tenacity:
Flexible
Cleavage:
Perfect
{001}
{001}
Density:
2.83 - 2.90 g/cm3 (Measured) 2.80 g/cm3 (Calculated)
Optical Data of Tainiolite
Type:
Biaxial (-)
RI values:
nα = 1.522 - 1.541 nβ = 1.553 - 1.570 nγ = 1.553 - 1.570
2V:
Measured: 2° to 5°
Max. Birefringence:
δ = 0.029 - 0.031
Based on recorded range of RI values above.
Based on recorded range of RI values above.
Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
Surface Relief:
Moderate
Dispersion:
r > v or r < v
Pleochroism:
Visible
Comments:
X = colorless to pale greenish brown; Y = Z = yellowish to reddish brown.
Chemistry of Tainiolite
Mindat Formula:
KLiMg2(Si4O10)F2
Element Weights:
Crystallography of Tainiolite
Crystal System:
Monoclinic
Class (H-M):
2/m - Prismatic
Space Group:
B2/m
Setting:
C2/m
Cell Parameters:
a = 5.254(2) Å, b = 9.110(4) Å, c = 10.187(2) Å
β = 99.85(4)°
β = 99.85(4)°
Ratio:
a:b:c = 0.577 : 1 : 1.118
Unit Cell V:
480.40 ų (Calculated from Unit Cell)
Z:
2
Twinning:
Penetration trillings rare
Crystal Structure
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File Best | x | y | z | a | b | c
CIF File Best | x | y | z | a | b | c
Rotation
Stop | Start
Stop | Start
Labels
Console Off | On | Grey | Yellow
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0010797 | Tainiolite | Toraya H, Iwai S, Marumo F, Hirao M (1977) The crystal structure of taeniolite, KLiMg2Si4O10F2 Zeitschrift fur Kristallographie 146 73-83 |  | 1977 | synthetic | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder Diffraction
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 3.34 Å | (100) |
| 10.04 Å | (74) |
| 5.01 Å | (44) |
| 1.999 Å | (35) |
| 3.12 Å | (26) |
| 2.88 Å | (25) |
| 3.60 Å | (17) |
Comments:
1M.
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| Stage 4b: Highly evolved igneous rocks | >3.0 |
| 35 : Ultra-alkali and agpaitic igneous rocks | |
| 36 : Carbonatites, kimberlites, and related igneous rocks |
Type Occurrence of Tainiolite
Place of Conservation of Type Material:
University of Copenhagen, Copenhagen, Denmark.
Geological Setting of Type Material:
nepheline syenite pegmatites.
Associated Minerals at Type Locality:
Synonyms of Tainiolite
Other Language Names for Tainiolite
Relationship of Tainiolite to other Species
Member of:
Other Members of Trioctahedral mica:
| Aspidolite | NaMg3(AlSi3O10)(OH)2 | Mon. 2/m : B2/m |
| Balestraite | KLi2V5+Si4O12 | Mon. 2 : B2 |
| Biotite | K(Fe2+/Mg)2(Al/Fe3+/Mg/Ti)([Si/Al/Fe]2Si2O10)(OH/F)2 | |
| Ephesite | NaLiAl2(Al2Si2O10)(OH)2 | Tric. 1 : P1 |
| Garmite | CsLiMg2(Si4O10)F2 | Mon. |
| Hendricksite | KZn3(Si3Al)O10(OH)2 | Mon. 2/m : B2/m |
| Kreiterite | CsLi2Fe3+(Si4O10)F2 | Mon. |
| Lepidolite | A field name for the group of Li-rich micas in, or close to, the so-called Polylithionite-Trilithionite ... | |
| Masutomilite | K(LiAlMn2+)[AlSi3O10]F2 | Mon. 2 : B2 |
| Norrishite | KLiMn3+2(Si4O10)O2 | Mon. 2/m : B2/m |
| Orlovite | KLi2Ti(Si4O10)OF | Mon. 2 : B2 |
| Preiswerkite | NaMg2Al(Al2Si2O10)(OH)2 | Mon. 2/m : B2/b |
| Shirokshinite | K(NaMg2)(Si4O10)F2 | Mon. 2/m : B2/m |
| Shirozulite | KMn2+3(Si3Al)O10(OH)2 | Mon. 2/m : B2/m |
| Sokolovaite | CsLi2Al(Si4O10)F2 | Mon. |
| Suhailite | (NH4)Fe2+3(AlSi3O10)(OH)2 | Mon. 2/m : B2/m |
| Wonesite | (Na,K)(Mg,Fe,Al)6((Al,Si)4O10)2(OH,F)4 | Mon. 2/m : B2/m |
| Zinnwaldite | Mica Group. |
Common Associates
Associated Minerals Based on Photo Data:
| 10 photos of Tainiolite associated with Polylithionite | KLi2Al(Si4O10)(F,OH)2 |
| 6 photos of Tainiolite associated with Todorokite | (Na,Ca,K,Ba,Sr)1-x(Mn,Mg,Al)6O12 · 3-4H2O |
| 6 photos of Tainiolite associated with Zirconium-bearing Halloysite | Al2(Si2O5)(OH)4 |
| 6 photos of Tainiolite associated with Rutile | TiO2 |
| 4 photos of Tainiolite associated with Leifite | (Na,H2O)Na6[Be2Al2(Al,Si)Si15O39]F2 |
| 3 photos of Tainiolite associated with Aegirine | NaFe3+Si2O6 |
| 3 photos of Tainiolite associated with Pectolite | NaCa2Si3O8(OH) |
| 2 photos of Tainiolite associated with Manganoneptunite | KNa2Li(Mn2+)2Ti2[Si4O12]2 |
| 2 photos of Tainiolite associated with Manganese-bearing Fluorapatite | (Ca,Mn2+)5(PO4)3(F,Cl,OH) or Ca5([P,Mn5+]O4)3(F,Cl,OH) |
| 2 photos of Tainiolite associated with Serandite | NaMn2+2Si3O8(OH) |
Related Minerals - Strunz-mindat Grouping
| 9.EC. | Meifuite | KFe6(Si7Al)O19(OH)4Cl2 |
| 9.EC. | Balestraite | KLi2V5+Si4O12 |
| 9.EC.05 | Talc | Mg3Si4O10(OH)2 |
| 9.EC.05 | Minnesotaite | Fe2+3Si4O10(OH)2 |
| 9.EC.05 | Willemseite | Ni3Si4O10(OH)2 |
| 9.EC.9.EC. | Voloshinite | Rb(LiAl1.5◻0.5)(Al0.5Si3.5)O10F2 |
| 9.EC.10 | Fluorluanshiweiite | KLiAl1.5(Si3.5Al0.5)O10F2 |
| 9.EC.10 | Garmite | CsLiMg2(Si4O10)F2 |
| 9.EC.10 | Gorbunovite | CsLi2(Ti,Fe)Si4O10(F,OH,O)2 |
| 9.EC.10 | Ferripyrophyllite | Fe3+Si2O5(OH) |
| 9.EC.10 | Manganiceladonite | K(MgMn3+◻)(Si4O10)(OH)2 |
| 9.EC.10 | Luanshiweiite | KLiAl1.5(Si3.5Al0.5)O10(OH)2 |
| 9.EC.10 | Pyrophyllite | Al2Si4O10(OH)2 |
| 9.EC.15 | Paragonite | NaAl2(AlSi3O10)(OH)2 |
| 9.EC.15 | Ferroaluminoceladonite | K(Fe2+Al◻)(Si4O10)(OH)2 |
| 9.EC.15 | Nanpingite | CsAl2(AlSi3O10)(OH,F)2 |
| 9.EC.15 | Ferroceladonite | K(Fe2+Fe3+◻)(Si4O10)(OH)2 |
| 9.EC.15 | Ganterite | (Ba,Na,K)(Al,Mg)2(AlSi3O10)(OH)2 |
| 9.EC.15 | Kreiterite | CsLi2Fe3+(Si4O10)F2 |
| 9.EC.15 | Roscoelite | KV3+2(AlSi3O10)(OH)2 |
| 9.EC.15 | Aluminoceladonite | K(MgAl◻)(Si4O10)(OH)2 |
| 9.EC.15 | Tobelite | (NH4)Al2(AlSi3O10)(OH)2 |
| 9.EC.15 | Celadonite | K(MgFe3+◻)(Si4O10)(OH)2 |
| 9.EC.15 | Chromceladonite | K(MgCr◻)(Si4O10)(OH)2 |
| 9.EC.15 | Montdorite | KFe2+1.5Mn2+0.5Mg0.5Si4O10(F,OH)2 |
| 9.EC.15 | Chromphyllite | KCr2(AlSi3O10)(OH)2 |
| 9.EC.15 | Boromuscovite | KAl2(BSi3O10)(OH)2 |
| 9.EC.15 | UM1988-22-SiO:AlCaFFeHKLiMg | KLiMgAl2Si3O10F2 |
| 9.EC.15 | Chernykhite | (Ba,Na)(V3+,Al,Mg)2((Si,Al)4O10)(OH)2 |
| 9.EC.15 | Muscovite | KAl2(AlSi3O10)(OH)2 |
| 9.EC.20 | Masutomilite | K(LiAlMn2+)[AlSi3O10]F2 |
| 9.EC.20 | Oxyphlogopite | K(Mg,Ti,Fe)3[(Si,Al)4O10](O,F)2 |
| 9.EC.20 | Chloroferrokinoshitalite | (Ba,K)(Fe2+,Mg)3(Al2Si2O10)(Cl,OH,F)2 |
| 9.EC.20 | Siderophyllite | KFe2+2Al(Al2Si2O10)(OH)2 |
| 9.EC.20 | Sokolovaite | CsLi2Al(Si4O10)F2 |
| 9.EC.20 | Hendricksite | KZn3(Si3Al)O10(OH)2 |
| 9.EC.20 | Tetraferriphlogopite | KMg3(Fe3+Si3O10)(OH,F)2 |
| 9.EC.20 | Fluorannite | KFe2+3(Si3Al)O10F2 |
| 9.EC.20 | Aspidolite | NaMg3(AlSi3O10)(OH)2 |
| 9.EC.20 | Suhailite | (NH4)Fe2+3(AlSi3O10)(OH)2 |
| 9.EC.20 | Ephesite | NaLiAl2(Al2Si2O10)(OH)2 |
| 9.EC.20 | Norrishite | KLiMn3+2(Si4O10)O2 |
| 9.EC.20 | Phlogopite | KMg3(AlSi3O10)(OH)2 |
| 9.EC.20 | Yangzhumingite | KMg2.5(Si4O10)F2 |
| 9.EC.20 | Orlovite | KLi2Ti(Si4O10)OF |
| 9.EC.20 | Tetraferriannite | KFe2+3(Si3Fe3+)O10(OH)2 |
| 9.EC.20 | Shirokshinite | K(NaMg2)(Si4O10)F2 |
| 9.EC.20 | Trilithionite | K(Li1.5Al1.5)(AlSi3O10)(F,OH)2 |
| 9.EC.20 | Polylithionite | KLi2Al(Si4O10)(F,OH)2 |
| 9.EC.20 | Shirozulite | KMn2+3(Si3Al)O10(OH)2 |
| 9.EC.20 | Preiswerkite | NaMg2Al(Al2Si2O10)(OH)2 |
| 9.EC.20 | Fluorophlogopite | KMg3(Si3Al)O10F2 |
| 9.EC.20 | Wonesite | (Na,K)(Mg,Fe,Al)6((Al,Si)4O10)2(OH,F)4 |
| 9.EC.20 | UM2004-49-SiO:AlCsFHKLi | (Cs,K)(Al,Li)2.6((Si,Al)4O10)(F,OH)2 |
| 9.EC.20 | Fluorotetraferriphlogopite | KMg3(Fe3+Si3O10)F2 |
| 9.EC.20 | Annite | KFe2+3(AlSi3O10)(OH)2 |
| 9.EC.20 | Eastonite | KMg2Al(Al2Si2O10)(OH)2 |
| 9.EC.22 | Pimelite | Ni3Si4O10(OH)2 · 4H2O |
| 9.EC.30 | Margarite | CaAl2(Al2Si2O10)(OH)2 |
| 9.EC.30 | Chlorophaeite | (Ca,Mg,Fe)2Fe2Si4O13 · 10H2O |
| 9.EC.35 | Kinoshitalite | (Ba,K)(Mg,Mn2+,Al)3(Al2Si2O10)(OH)2 |
| 9.EC.35 | Ferrokinoshitalite | (Ba,K)(Fe2+,Mg)3(Al2Si2O10)(OH,F)2 |
| 9.EC.35 | Clintonite | CaAlMg2(SiAl3O10)(OH)2 |
| 9.EC.35 | Oxykinoshitalite | (Ba,K)(Mg,Ti,Fe3+,Fe2+)3((Si,Al)4O10)(O,OH,F)2 |
| 9.EC.35 | Fluorokinoshitalite | BaMg3(Al2Si2O10)F2 |
| 9.EC.35 | Bityite | CaLiAl2(AlBeSi2O10)(OH)2 |
| 9.EC.35 | Anandite | (Ba,K)(Fe2+,Mg)3((Si,Al,Fe)4O10)(S,OH)2 |
| 9.EC.40 | Montmorillonite | (Na,Ca)0.33(Al,Mg)2(Si4O10)(OH)2 · nH2O |
| 9.EC.40 | Beidellite | (Na,Ca0.5)0.3Al2((Si,Al)4O10)(OH)2 · nH2O |
| 9.EC.40 | Volkonskoite | Ca0.3(Cr,Mg,Fe)2((Si,Al)4O10)(OH)2 · 4H2O |
| 9.EC.40 | Nontronite | Na0.3Fe2((Si,Al)4O10)(OH)2 · nH2O |
| 9.EC.40 | Kurumsakite | (Zn,Ni,Cu)8Al8V5+2Si5O35 · 27H2O (?) |
| 9.EC.40 | Yakhontovite | (Ca,Na)0.5(Cu,Fe,Mg)2(Si4O10)(OH)2 · 3H2O |
| 9.EC.45 | Swinefordite | Li(Al,Li,Mg)3((Si,Al)4O10)2(OH,F)4 · nH2O |
| 9.EC.45 | Hectorite | Na0.3(Mg,Li)3(Si4O10)(F,OH)2 |
| 9.EC.45 | Zincsilite | Zn3Si4O10(OH)2 · 4H2O (?) |
| 9.EC.45 | Hanjiangite | Ba2CaV3+Al(H2AlSi3O12)(CO3)2F |
| 9.EC.45 | Spadaite | MgSiO2(OH)2 · H2O (?) |
| 9.EC.45 | Ferrosaponite | Ca0.3(Fe2+,Mg,Fe3+)3((Si,Al)4O10)(OH)2 · 4H2O |
| 9.EC.45 | Stevensite | (Ca,Na)xMg3-x(Si4O10)(OH)2 |
| 9.EC.45 | Saponite | Ca0.25(Mg,Fe)3((Si,Al)4O10)(OH)2 · nH2O |
| 9.EC.45 | Sauconite | Na0.3Zn3((Si,Al)4O10)(OH)2 · 4H2O |
| 9.EC.50 | Vermiculite | Mg0.7(Mg,Fe,Al)6(Si,Al)8O20(OH)4 · 8H2O |
| 9.EC.52 | Tarasovite | near NaKAl11Si13O40(OH)9 · 3H2O |
| 9.EC.55 | Clinochlore | Mg5Al(AlSi3O10)(OH)8 |
| 9.EC.55 | Borocookeite | (LiAl4◻)[BSi3O10](OH)8 |
| 9.EC.55 | Franklinfurnaceite | Ca2Fe3+Mn2+3Mn3+(Zn2Si2O10)(OH)8 |
| 9.EC.55 | Pennantite | Mn2+5Al(AlSi3O10)(OH)8 |
| 9.EC.55 | Vakhrushevaite | Mg5Cr(AlSi3O10)(OH)8 |
| 9.EC.55 | Nimite | (Ni,Mg,Al)6((Si,Al)4O10)(OH)8 |
| 9.EC.55 | Cookeite | (LiAl4◻)[AlSi3O10](OH)8 |
| 9.EC.55 | Gonyerite | (Mn2+,Mg)5Fe3+(Fe3+Si3O10)(OH)8 |
| 9.EC.55 | Chamosite | (Fe2+,Mg,Al,Fe3+)6(Si,Al)4O10(OH,O)8 |
| 9.EC.55 | Orthochamosite | (Fe2+,Mg,Fe3+)5Al(AlSi3O10)(OH,O)8 |
| 9.EC.55 | Baileychlore | (Zn,Fe2+,Al,Mg)6(Si,Al)4O10(OH)8 |
| 9.EC.55 | Sudoite | Mg2Al3(Si3Al)O10)(OH)8 |
| 9.EC.55 | Glagolevite | Na(Mg,Al)6(AlSi3O10)(OH,O)8 |
| 9.EC.55 | Donbassite | Al4.33(Si3Al)O10(OH)8 |
| 9.EC.60 | Dozyite | Mg7Al2(Al2Si4O15)(OH)12 |
| 9.EC.60 | Rectorite | (Na,Ca)Al4((Si,Al)8O20)(OH)4 · 2H2O |
| 9.EC.60 | Corrensite | (Mg,Fe)9((Si,Al)8O20)(OH)10 · nH2O |
| 9.EC.60 | Aliettite | Ca0.2Mg6((Si,Al)8O20)(OH)4 · 4H2O |
| 9.EC.60 | Karpinskite | (Ni,Mg)2Si2O5(OH)2 (?) |
| 9.EC.60 | Lunijianlaite | Li0.7Al6.2(AlSi7O20)(OH,O)10 |
| 9.EC.60 | Tosudite | Na0.5(Al,Mg)6((Si,Al)8O18)(OH)12 · 5H2O |
| 9.EC.60 | Hydrobiotite | K(Mg,Fe2+)6((Si,Al)8O20)(OH)4 · nH2O |
| 9.EC.60 | Saliotite | (Li,Na)Al3(AlSi3O10)(OH)5 |
| 9.EC.60 | Kulkeite | Mg8Al(AlSi7O20)(OH)10 |
| 9.EC.60 | Brinrobertsite | Na0.3Al4(Si4O10)2(OH)4 · 3.5 H2O |
| 9.EC.65 | Macaulayite | (Fe,Al)24Si4O43(OH)2 |
| 9.EC.70 | Burckhardtite | Pb2(Fe3+Te6+)[AlSi3O8]O6 |
| 9.EC.75 | Niksergievite | (Ba,Ca)2Al3(AlSi3O10)(CO3)(OH)6 · nH2O |
| 9.EC.75 | Ferrisurite | (Pb,Ca)2.4Fe3+2(Si4O10)(CO3)1.7(OH)3 · nH2O |
| 9.EC.75 | Surite | (Pb,Ca)3(Al,Fe2+,Mg)2((Si,Al)4O10)(CO3)2(OH)2 |
| 9.EC.80 | Kegelite | Pb8Al4(Si8O20)(SO4)2(CO3)4(OH)8 |
Radioactivity
Radioactivity:
| Element | % Content | Activity (Bq/kg) | Radiation Type |
|---|---|---|---|
| Uranium (U) | 0.0000% | 0 | α, β, γ |
| Thorium (Th) | 0.0000% | 0 | α, β, γ |
| Potassium (K) | 9.6543% | 2,993 | β, γ |
For comparison:
- Banana: ~15 Bq per fruit
- Granite: 1,000–3,000 Bq/kg
- EU exemption limit: 10,000 Bq/kg
Note: Risk is shown relative to daily recommended maximum exposure to non-background radiation of 1000 µSv/year. Note that natural background radiation averages around 2400 µSv/year so in reality these risks are probably extremely overstated! With infrequent handling and safe storage natural radioactive minerals do not usually pose much risk.
Interactive Simulator:
Note: The mass selector refers to the mass of radioactive mineral present, not the full specimen, also be aware that the matrix may also be radioactive, possibly more radioactive than this mineral!
Activity: –
| Distance | Dose rate | Risk |
|---|---|---|
| 1 cm | ||
| 10 cm | ||
| 1 m |
The external dose rate (D) from a radioactive mineral is estimated by summing the gamma radiation contributions from its Uranium, Thorium, and Potassium content, disregarding daughter-product which may have a significant effect in some cases (eg 'pitchblende'). This involves multiplying the activity (A, in Bq) of each element by its specific gamma ray constant (Γ), which accounts for its unique gamma emissions. The total unshielded dose at 1 cm is then scaled by the square of the distance (r, in cm) and multiplied by a shielding factor (μshield). This calculation provides a 'worst-case' or 'maximum risk' estimate because it assumes the sample is a point source and entirely neglects any self-shielding where radiation is absorbed within the mineral itself, meaning actual doses will typically be lower. The resulting dose rate (D) is expressed in microsieverts per hour (μSv/h).
D = ((AU × ΓU) + (ATh × ΓTh) + (AK × ΓK)) / r2 × μshield
Other Information
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for Tainiolite
mindat.org URL:
https://www.mindat.org/min-7325.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
References for Tainiolite
Reference List:
Rieder, M., Cavazzini, G., D’Yakonov, Y.S., Frank-Kamenetskii, V.A., Gottardt, G., Guggenheim, S., Koval, P.V., Muller, G., Neiva, A.M.R., Radoslovich, E.W., Robert, J.L., Sassi, F.P., Takeda, H., Weiss, Z., Wones, D.R. (1998) Nomenclature of the micas. The Canadian Mineralogist, 36 (3) 905-912
Localities for Tainiolite
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
Afghanistan | |
| Tucker et al. (2012) |
Brazil | |
| Traversa et al. (2001) |
| Traversa et al. (2001) | |
| Atencio et al. (1999) |
| Azzi (2019) +1 other reference | |
Canada | |
| Grice (1989) +1 other reference |
| Horváth et al. (1998) |
| HORVÁTH (2010) | |
China | |
| Le Bas et al. (1992) |
| Gao et al. (2024) |
| Gao et al. (2024) | |
| Daxian Zhao and Guangting Tang (1991) |
Finland | |
| Sarapää +8 other references |
| Ani et al. (2013) | |
Germany | |
| |
Greenland (TL) | |
| Bøggild (1953) |
Italy | |
| Piccoli et al. (2007) |
| Cabella R. et al. (1987) +2 other references | |
Japan | |
| Imaoka et al. (2024) |
Namibia | |
| Jour Pet 39:2123-2136. |
New Zealand | |
| Cooper et al. (2008) +1 other reference |
Norway | |
| Larsen et al. (2010) |
| Larsen et al. (2010) | |
Russia | |
| Konev et al. (1993) |
| A.M. Portnov data +2 other references |
| Sharygin +12 other references |
| PEKOV et al. (2013) |
| Pekov et al. (2004) | |
| Pekov et al. (2003) |
| |
| Yakovenchuk et al. (2011) | |
| Pekov (2003) |
| Pavel.M. Kartashov (n.d.) +1 other reference | |
| Pekov (1998) |
Spain | |
| Dill et al. (2023) |
| Dill et al. (2023) |
| Oberti +4 other references |
Tajikistan | |
| Pautov (2003) |
Tanzania | |
| Feneyrol et al. (2012) |
Ukraine | |
| Victor V. Sharygin analytycal data (2013) |
USA | |
| Smith (1988) |
| V.C. Fryklund and D.F. Holbrook (1950) |
| Smith (1988) | |
| Karl Estes (1998) | |
| Erickson +2 other references | |
| Rocks & Min.: 63:110. | |
| Rocks & Min.: 63:110. | |
| Rocks & Minerals 63:2 pp 104-125 | |
| Josh Varnedore Collection | |
| Rocks & Min.: 63:109. +2 other references | |
| ... +3 other references |
| Eckel et al. (1997) |
| Buchholt et al. (2015) |
| Buchholt et al. (2015) |
Quick NavTopAbout TainioliteUnique IdentifiersIMA Classification Classification Mineral SymbolsPhysical Properties Optical Data Chemistry Crystallography Crystal StructureX-Ray Powder DiffractionGeological EnvironmentType Occurrence SynonymsOther LanguagesRelationshipsCommon AssociatesStrunz-MindatRadioactivityOther InformationInternet Links References Localities Locality List
The Varnedore Prospect, Magnet Cove, Hot Spring County, Arkansas, USA
