Mottramite
A valid IMA mineral species - grandfathered
This page is currently not sponsored. Click here to sponsor this page.
About Mottramite
Formula:
PbCu(VO4)(OH)
Colour:
Grass-green, olive-green, yellow-green, siskin-green, blackish brown, nearly black
Lustre:
Greasy
Hardness:
3 - 3½
Specific Gravity:
5.9
Crystal System:
Orthorhombic
Member of:
Name:
For the locality at Mottram St. Andrew, Cheshire, England where ore was stockpiled. Most likely mined from Pim Hill Mine, Shrewsbury, Shropshire.
Type Locality:
Adelite-Descloizite Group. Descloizite-Mottramite Series. Duftite-Mottramite Series.
The copper analogue of Descloizite.
A secondary mineral frequently found principally in the oxidized zones of ore deposits.
The copper analogue of Descloizite.
A secondary mineral frequently found principally in the oxidized zones of ore deposits.
Unique Identifiers
Mindat ID:
2792
Long-form identifier:
mindat:1:1:2792:8
IMA Classification of Mottramite
Approved, 'Grandfathered' (first described prior to 1959)
Classification of Mottramite
8.BH.40
8 : PHOSPHATES, ARSENATES, VANADATES
B : Phosphates, etc., with additional anions, without H2O
H : With medium-sized and large cations, (OH,etc.):RO4 = 1:1
8 : PHOSPHATES, ARSENATES, VANADATES
B : Phosphates, etc., with additional anions, without H2O
H : With medium-sized and large cations, (OH,etc.):RO4 = 1:1
41.5.2.2
41 : ANHYDROUS PHOSPHATES, ETC.CONTAINING HYDROXYL OR HALOGEN
5 : (AB)2(XO4)Zq
41 : ANHYDROUS PHOSPHATES, ETC.CONTAINING HYDROXYL OR HALOGEN
5 : (AB)2(XO4)Zq
21.3.10
21 : Vanadates (and vanadates with arsenate or phosphate)
3 : Vanadates of Al, rare earths, Pb, V or Bi
21 : Vanadates (and vanadates with arsenate or phosphate)
3 : Vanadates of Al, rare earths, Pb, V or Bi
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference |
|---|---|---|
| Mott | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Physical Properties of Mottramite
Greasy
Transparency:
Transparent, Opaque
Colour:
Grass-green, olive-green, yellow-green, siskin-green, blackish brown, nearly black
Comment:
Crystals often exhibit zonal growth with varying colours.
Streak:
Yellowish green
Hardness:
3 - 3½ on Mohs scale
Comment:
Hardness somewhat harder on crystal surfaces.
Tenacity:
Brittle
Cleavage:
None Observed
Fracture:
Irregular/Uneven, Sub-Conchoidal
Density:
5.9 g/cm3 (Measured) 6.187 g/cm3 (Calculated)
Optical Data of Mottramite
Type:
Biaxial (-)
RI values:
nα = 2.17(2) nβ = 2.26(2) nγ = 2.32(2)
2V:
Measured: 73° , Calculated: 46°
Max. Birefringence:
δ = 0.150
Based on recorded range of RI values above.
Based on recorded range of RI values above.
Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
Surface Relief:
Moderate
Dispersion:
strong r > v rarely r < v
Pleochroism:
Visible
Comments:
Weak to strong
X=Y= canary yellow to greenish yellow
Z= brownish yellow
X=Y= canary yellow to greenish yellow
Z= brownish yellow
Chemistry of Mottramite
Mindat Formula:
PbCu(VO4)(OH)
Element Weights:
Common Impurities:
Zn
Crystallography of Mottramite
Crystal System:
Orthorhombic
Class (H-M):
mmm (2/m 2/m 2/m) - Dipyramidal
Space Group:
Pnma
Cell Parameters:
a = 7.68 Å, b = 9.27 Å, c = 6.03 Å
Ratio:
a:b:c = 0.828 : 1 : 0.65
Unit Cell V:
429.30 ų (Calculated from Unit Cell)
Z:
4
Morphology:
Crystals equant, dipyramidal {111}, prismatic [001]. Drusy crusts of intergrown crystals common; mammillary or botryoidal surfaces.
Crystal Structure
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File Best | x | y | z | a | b | c
CIF File Best | x | y | z | a | b | c
Rotation
Stop | Start
Stop | Start
Labels
Console Off | On | Grey | Yellow
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0005468 | Mottramite | Cooper M A, Hawthorne F C (1995) The crystal structure of mottramite, and the nature of Cu=Zn solid solution in the mottramite-descloizite series The Canadian Mineralogist 33 1119-1124 |  | 1995 | 0 | 293 | |
| 0012569 | Mottramite | Permer L, Laligant Y, Ferey G (1993) Crystal structure of (Pb2.8Fe1.2)Cu4O1.6(VO4)4(OH)2; structural relationships with mineral gamagarite _cod_database_code 1000426 European Journal of Solid State and Inorganic Chemistry 30 383-392 | 1993 | 0 | 293 | ||
| 0019267 | Mottramite | Krause W, Kolitsch U, Bernhardt H J, Effenberger H (2003) Duhamelite discredited Neues Jahrbuch fur Mineralogie, Monatshefte 2003 75-96 | 2003 | Shaba, Congo | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder Diffraction
Loading XRD data...
Data courtesy of RRUFF project at University of Arizona, used with permission.
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 3.24 Å | (vvs) |
| 5.07 Å | (vs) |
| 2.87 Å | (vs) |
| 2.68 Å | (vs) |
| 2.66 Å | (vs) |
| 2.59 Å | (vs) |
| 1.648 Å | (vs) |
Comments:
Mottram St. Andrew, England. Pattern is similar to descloizite.
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| High-? alteration and/or metamorphism | |
| 32 : Ba/Mn/Pb/Zn deposits, including metamorphic deposits | |
| Stage 7: Great Oxidation Event | <2.4 |
| 47a : [Near-surface hydration of prior minerals] | |
| 47d : [Arsenates, antimonates, selenates, bismuthinates] | |
| 47e : [Vanadates, chromates, manganates] |
Geological Setting:
Oxidation zone of vanadium bearing base metal deposits.
Type Occurrence of Mottramite
Place of Conservation of Type Material:
Natural History Museum London 52314-52315
Synonyms of Mottramite
Other Language Names for Mottramite
Dutch:Mottramiet
Italian:Vesbina
Russian:Моттрамит
Simplified Chinese:羟钒铜铅石
Spanish:Mottramita
Traditional Chinese:羥釩銅鉛石
Varieties of Mottramite
| Duhamelite | Ca- and Bi-bearing variety of mottramite, typically with acicular habit. Discredited as a mineral species. For the Bi-dominant member, see khorixasite. Originally reported from Lousy Gulch, Payson area, Payson District (Green Valley District), Gila Co.,... |
Relationship of Mottramite to other Species
Member of:
Other Members of Adelite-Descloizite Group:
| Adelite | CaMg(AsO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Arsendescloizite | PbZn(AsO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Austinite | CaZn(AsO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Čechite | PbFe2+(VO4)(OH) | Orth. mmm (2/m 2/m 2/m) |
| Cobaltaustinite | CaCo(AsO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Conichalcite | CaCu(AsO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Descloizite | PbZn(VO4)(OH) | Orth. mmm (2/m 2/m 2/m) : Pnma |
| Duftite | PbCu(AsO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Duftite-alpha | PbCu(AsO4)(OH) | |
| Gottlobite | CaMg(VO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Hermannroseite | CaCu(PO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Nickelaustinite | CaNi(AsO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Pyrobelonite | PbMn2+(VO4)(OH) | Orth. mmm (2/m 2/m 2/m) : Pnma |
| Tangeite | CaCu(VO4)(OH) | Orth. 2 2 2 : P21 21 21 |
| Unnamed (Pb-analogue of Nickelaustinite) | PbNi(AsO4)(OH) | |
| Vuagnatite | CaAl(SiO4)(OH) | Orth. 2 2 2 : P21 21 21 |
Forms a series with:
Common Associates
Associated Minerals Based on Photo Data:
| 452 photos of Mottramite associated with Calcite | CaCO3 |
| 199 photos of Mottramite associated with Vanadinite | Pb5(VO4)3Cl |
| 132 photos of Mottramite associated with Wulfenite | Pb(MoO4) |
| 105 photos of Mottramite associated with Quartz | SiO2 |
| 64 photos of Mottramite associated with Dioptase | CuSiO3 · H2O |
| 59 photos of Mottramite associated with Pyromorphite | Pb5(PO4)3Cl |
| 50 photos of Mottramite associated with Cerussite | PbCO3 |
| 44 photos of Mottramite associated with Phosphohedyphane | Ca2Pb3(PO4)3Cl |
| 37 photos of Mottramite associated with Mimetite | Pb5(AsO4)3Cl |
| 26 photos of Mottramite associated with Arsenic-bearing Vanadinite | Pb5[(V,As)O4]3Cl |
Related Minerals - Strunz-mindat Grouping
| 8.BH. | Peterchinite | Zn3Zn2(OH)6As[O3(OH)3] |
| 8.BH. | Reznitskyite | CaMg(VO4)F |
| 8.BH. | Cuprozheshengite | Pb4CuZn2(AsO4)2(PO4)2(OH)2 |
| 8.BH. | Zheshengite | Pb4ZnZn2(AsO4)2(PO4)2(OH)2 |
| 8.BH. | Crimsonite | PbFe3+2(PO4)2(OH)2 |
| 8.BH.05 | Thadeuite | Ca(Mg,Fe2+)3(PO4)2(OH,F)2 |
| 8.BH.10 | Panasqueiraite | CaMg(PO4)(OH) |
| 8.BH.10 | Isokite | CaMg(PO4)F |
| 8.BH.10 | Lacroixite | NaAl(PO4)F |
| 8.BH.10 | Arsenatrotitanite | NaTi(AsO4)O |
| 8.BH.10 | Maxwellite | NaFe3+(AsO4)F |
| 8.BH.10 | Durangite | NaAl(AsO4)F |
| 8.BH.10 | Kononovite | NaMg(SO4)F |
| 8.BH.15 | Drugmanite | Pb2Fe3+(PO4)(PO3OH)(OH)2 |
| 8.BH.20 | Nigelcookite | PbFe2+2V3+2(PO4)3(OH)3 |
| 8.BH.20 | Plumbojohntomaite | PbFe2+2Fe3+2(PO4)3(OH)3 |
| 8.BH.20 | Cirrolite | Ca3Al2(PO4)3(OH)3 (?) |
| 8.BH.20 | Penikisite | Ba(Mg,Fe2+,Ca)2Al2(PO4)3(OH)3 |
| 8.BH.20 | Perloffite | Ba(Mn2+,Fe2+)2Fe3+2(PO4)3(OH)3 |
| 8.BH.20 | Bjarebyite Group | |
| 8.BH.20 | Strontioperloffite | SrMn2+2Fe3+2(PO4)3(OH)3 |
| 8.BH.20 | Plumboperloffite | PbMn2+2Fe3+2(PO4)3(OH)3 |
| 8.BH.20 | Johntomaite | BaFe2+2Fe3+2(PO4)3(OH)3 |
| 8.BH.20 | Bjarebyite | (Ba,Sr)(Mn2+,Fe2+,Mg)2Al2(PO4)3(OH)3 |
| 8.BH.20 | Kulanite | Ba(Fe2+,Mn2+,Mg)2(Al,Fe3+)2(PO4)3(OH)3 |
| 8.BH.25 | Bertossaite | Li2CaAl4(PO4)4(OH)4 |
| 8.BH.25 | Natropalermoite | Na2SrAl4(PO4)4(OH)4 |
| 8.BH.25 | Palermoite | Li2SrAl4(PO4)4(OH)4 |
| 8.BH.30 | Sewardite | CaFe3+2(AsO4)2(OH)2 |
| 8.BH.30 | Carminite | PbFe3+2(AsO4)2(OH)2 |
| 8.BH.35 | Adelite | CaMg(AsO4)(OH) |
| 8.BH.35 | Duftite | PbCu(AsO4)(OH) |
| 8.BH.35 | Cobaltaustinite | CaCo(AsO4)(OH) |
| 8.BH.35 | Nickelaustinite | CaNi(AsO4)(OH) |
| 8.BH.35 | Gabrielsonite | PbFe3+(As3+O3)O |
| 8.BH.35 | Conichalcite | CaCu(AsO4)(OH) |
| 8.BH.35 | Arsendescloizite | PbZn(AsO4)(OH) |
| 8.BH.35 | Duftite-alpha | PbCu(AsO4)(OH) |
| 8.BH.35 | Gottlobite | CaMg(VO4)(OH) |
| 8.BH.35 | Austinite | CaZn(AsO4)(OH) |
| 8.BH.35 | Hermannroseite | CaCu(PO4)(OH) |
| 8.BH.35 | Tangeite | CaCu(VO4)(OH) |
| 8.BH.40 | Čechite | PbFe2+(VO4)(OH) |
| 8.BH.40 | Khorixasite | (Bi0.67◻0.33)Cu(VO4)(OH) |
| 8.BH.40 | Descloizite | PbZn(VO4)(OH) |
| 8.BH.40 | Pyrobelonite | PbMn2+(VO4)(OH) |
| 8.BH.45 | Bayldonite | PbCu3(AsO4)2(OH)2 |
| 8.BH.45 | Vésigniéite | BaCu3(VO4)2(OH)2 |
| 8.BH.50 | Paganoite | NiBi(AsO4)O |
| 8.BH.55 | Jagowerite | BaAl2(PO4)2(OH)2 |
| 8.BH.55 | Harrisonite | Ca(Fe2+,Mg)6(PO4)2(SiO4)2 |
| 8.BH.60 | Attakolite | CaMn2+Al4(SiO3OH)(PO4)3(OH)4 |
| 8.BH.65 | Leningradite | PbCu3(VO4)2Cl |
| 8.BH.70 | Katiarsite | KTiO(AsO4) |
| 8.BH.70 | Yurgensonite | K2SnTiO2(AsO4)2 |
| 8.BH.75 | Melanarsite | K3Cu7Fe3+O4(AsO4)4 |
| 8.BH.80 | Evseevite | Na2Mg(AsO4)F |
| 8.BH.80 | Moraskoite | Na2Mg(PO4)F |
| 8.BH.85 | Piccoliite | NaCaMn3+2(AsO4)2O(OH) |
Other Information
Electrical:
Readily soluble in acids.
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for Mottramite
mindat.org URL:
https://www.mindat.org/min-2792.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
References for Mottramite
Reference List:
Genth, F. A. (1874) Contributions from the Laboratory of the University of Pennsylvania. No. III. On American Tellurium and Bismuth Minerals. Proceedings of the American Philosophical Society, 14. 223-231p.229 - as Psittacinite
Roscoe, H. E. (1877) IV. On two new vanadium minerals. Proceedings of the Royal Society of London, 25 (171) 109-112 doi:10.1098/rspl.1876.0023
Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 p.64 - (as cuprodescloizite)
Zambonini, F., Washington, G. Carobbi. Abstract by Henry S. (1927) A chemical study of the yellow incrustations on the Vesuvian lava of 1631. American Mineralogist, 12 (1) 1-9 as Vesbine
Bannister, F. A. (1933) The identity of mottramite and psittacinite with cupriferous descloizite. Mineralogical Magazine and Journal of the Mineralogical Society, 23 (141) 376-386 doi:10.1180/minmag.1933.023.141.04
Schaller, Waldemar T. (1934) Mottramite or psittacinite - a question of nomenclature. American Mineralogist, 19 (4). 180-181
Kingsbury, Arthur W. G., Hartley, J. (1956) New occurrences of vanadium minerals (mottramite, descloizite, and vanadinite) in the Caldbeck area of Cumberland. Mineralogical Magazine and Journal of the Mineralogical Society, 31 (235) 289-295 doi:10.1180/minmag.1956.031.235.02
Rahden, Herbert V. R. Von, Dicks, Lynton W. R. (1967) Descloizite, mottramite, and vanadinite from South West Africa: an infrared and X-ray study. American Mineralogist, 52 (7-8) 1067-1076
van der Westhuizen, W. A., de Bruiyn, H., Tordiffe, E. A. W., Botha, B. J. V. (1986) The descloizite-mottramite series of vanadates from the Otavi Mountain Land, South West Africa: an X-ray study. Mineralogical Magazine, 50 (355) 137-140 doi:10.1180/minmag.1986.050.355.18
Frost, Ray L., Williams, Peter A., Theo Kloprogge, J., Leverett, P. (2001) Raman spectroscopy of descloizite and mottramite at 298 and 77 K. Journal of Raman Spectroscopy, 32 (11). 906-911 doi:10.1002/jrs.758
Lakshmi Reddy, S., Reddy, K.N.M., Siva Reddy, G., Endo, Tamio, Frost, R.L. (2010) Optical absorption near infrared and EPR studies of mottramite. Molecular Physics, 108. 1467-1470 doi:10.1080/00268971003718425
Frost, Ray L., Xi, Yunfei, López, Andrés, Corrêa, Lívia, Scholz, Ricardo (2014) The molecular structure of the vanadate mineral mottramite [PbCu(VO4)(OH)] from Tsumeb, Namibia – A vibrational spectroscopic study. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 122. 252-256 doi:10.1016/j.saa.2013.11.086
Localities for Mottramite
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
Angola | |
| Millmam (1960) |
Argentina | |
| Biglia et al. (2016) |
| Mr. Nelson Valenzuela. |
| Colombo et al. (2006) |
| [var: Duhamelite] Samples acquired from Nelson Valenzuela |
| Brodtkorb (2006) |
| Hayase et al. (1978) +1 other reference |
Australia | |
| Birch (1999) |
| Birch et al. (1997) |
| Sorrell (n.d.) |
| Dieter Mylius collection |
| [var: Duhamelite] Pring et al. (2000) |
| Nickel et al. (1993) |
| Nickel et al. (1993) | |
| Nickel (1987) |
| I.D. by Peter Elliott |
| Nickel et al. (1994) |
| Simpson Mineral Collection of the ... +7 other references |
| Simpson (1948) | |
| Murray Thompson +1 other reference |
| Downes et al. (2017) |
| Downes et al. (2017) | |
| Jorgensen et al. (2017) |
| Downes et al. (2011) |
Austria | |
| Auer (2018) |
| Auer et al. (2017) |
| Niedermayr et al. (1995) |
| Mikl et al. (2014) | |
| J. Taucher: Carinthia II 186./106.:132 (1996) | |
| M. Puttner: Carinthia II (1996) |
| Knobloch et al. (2021) |
| Kolitsch (2019) |
| Schachinger et al. (2015) |
| Strasser (1998) +1 other reference |
| Brandstätter et al. (2010) |
| Postl et al. (2006) |
| Lapis 29 (9) |
Azerbaijan | |
| Hemon et al. (2012) |
Bolivia | |
| Palache et al. (1951) |
Brazil | |
| Atencio et al. (2008) |
Canada | |
| Lines et al. (1996) |
| SASSANO et al. (1987) |
Chile | |
| Samples analysed by Dr. Jochen Schlüter (Hamburg University) |
| Mr. Terry Szenics. |
| samples analysed by Gerhard Mohn and ... |
| SEM-EDS by Joy Desor |
| SEM-EDS by Joy Desor | |
| maurizio dini collection - analysed ... | |
| Kampf et al. (2006) | |
| M.Dini & A.Molina collection +1 other reference |
| Palache et al. (1951) |
| Hubert Putz analytical data and ... |
Czech Republic | |
| Kohout et al. (1995) +1 other reference |
| Ondruš et al. (1989) | |
| J.Hyrsl (1992) | |
| Ondruš et al. (1989) | |
| Lapis 2002 (7/8) |
| Pauliš et al. (2004) |
| Sejkora et al. (2007) |
| Pauliš et al. (2009) +1 other reference |
DR Congo | |
| www.handbookofmineralogy.org (2012) |
| Wilson (2018) |
| [var: Duhamelite] Lhoest et al. (1991) +1 other reference |
Egypt | |
| Gatto Rotondo et al. (2012) |
| Afify et al. (2022) |
France | |
| Queneau (n.d.) |
| Yannick Vessely collection |
| Nicolas MEISSER analysis |
| Wittern et al. (1997) |
| Queneau (n.d.) |
| Jean-Robert et Christiane Eytier. +1 other reference |
| Collection Arliguie Michel +1 other reference |
| [var: Duhamelite] Robert PECORINI collection |
| inventoire mineralogique de la france ... |
| Lheur et al. (2010) +1 other reference |
| van den Berg (1987) +2 other references |
| Jean-Marie Claude collection +1 other reference | |
| Favreau et al. (2024) | |
Gabon | |
| Mineralogical Society of America - ... |
Germany | |
| Weiß (1990) |
| [Wittern (1995) |
| Walenta (1992) |
| Walenta (1992) |
| Walenta (1992) |
| Walenta (1989) +1 other reference |
| U. Kolitsch and R. Bayerl: Der Aufschluss 48 (4) |
| Habel (2001) |
| Schwarzmeier et al. (2015) +2 other references |
| Hauner (2024) |
| Hauner (2024) |
| PETITJEAN collection |
| Collection of Steffen Michalski |
| Collection of Steffen Michalski |
| Collection of Steffen Michalski | |
| S Wolfsried collection | |
| S Wolfsried collection | |
| Collection of Steffen Michalski |
| Collection of Steffen Michalski | |
| Lapis 25 (2) | |
| Legner et al. (2022) |
| Joachim Gröbner (2019) |
| Gröbner (2007) |
| Gröbner (2007) |
| Graf et al. (1992) |
| Schnorrer-Köhler (1988) |
| Christof Schäfer |
| Lapis 33 (12) |
| [var: Duhamelite] Blaß (1992) |
| Blass et al. (2006) | |
| Blass et al. (2006) |
| Blaß et al. (2006) +1 other reference |
| Personally collected by Günter Frenz |
| Hohn et al. (2015) |
| Brugger et al. (2001) |
| 81-82. +1 other reference |
| Witzke (2012) |
| Markus Gerstmann - Collection |
Greece | |
| Rieck et al. (2018) |
Israel | |
| Shlomovitch et al. (1996) |
Italy | |
| Scacchi (1879) +3 other references |
| Scacchi (1879) +1 other reference |
| Balassone et al. (2019) |
| Balassone et al. (2019) | |
| Locality description | |
| Carlini et al. (2018) |
| Bracco et al. (2014) |
| Castellaro-Kampf |
| Balestra C. et al. (2011) |
| Vergani et al. (2021) |
| Vergani F. et al. (2020) | |
| Guastoni et al. (2020) |
| Martini et al. (2012) |
| Martini et al. (2012) | |
| Bruno Marello et al. (2023) |
| Guastoni et al. (2006) +1 other reference |
| Guastoni et al. (2006) +1 other reference | |
| [var: Duhamelite] Olmi F. et al. (SS) |
| Mattioli et al. (2009) |
| Conedera M. et al. (2016) |
| Zordan et al. (2012) |
| Zordan et al. (2012) | |
Japan | |
| Hirama et al. (2011) |
| Komuro Minerals (Tokyo) |
| Shibuya & Lee (1984) |
| - (n.d.) |
| Sakurai and Kato (1959) | |
Kyrgyzstan | |
| Belova et al. (1985) +1 other reference |
| Belova et al. (1985) +1 other reference | |
Madagascar | |
| Behier (1963) |
Mexico | |
| Megaw (1990) |
| Fabre (n.d.) |
| Thorne (n.d.) |
| Lapis 2001 (1) | |
| [var: Duhamelite] Dakota Matrix specimen (Phillips collection) |
| Jones et al. (2021) |
Morocco | |
| Steve Rust specimen |
| Favreau (n.d.) |
| Praszkier (2013) |
| Praszkier (2013) |
| Praszkier (2013) | |
| Favreau et al. (2006) |
| Favreau (n.d.) |
| Fabre (n.d.) | |
| Notes Serv. Géol. Maroc |
Namibia | |
| Bezing et al. (2007) |
| von Bezing (2007) |
| [var: Duhamelite] Niedermayr (2001) |
| Niedermayr et al. (2008) +1 other reference |
| Schnaitmann et al. (2010) | |
| Palfi (2005) | |
| Schnaitmann et al. (2010) | |
| Schnaitmann et al. (2010) | |
| Niedermayr et al. (2010) | |
| Brandstätter +4 other references | |
| Cairncross (1997) |
| Cairncross (1997) |
| Elmar Lackner collection +2 other references | |
| Cairncross (1997) |
| Palache et al. (1951) | |
| Cairncross (1997) +1 other reference | |
| Palache et al. (1951) +1 other reference |
| von Bezing et al. (2016) |
| Palache et al. (1951) | |
| Woolf (2023) | |
| Cairncross (1997) +3 other references | |
| Dunn (1991) |
| Markham (1959) | |
| Cairncross (1997) +1 other reference | |
| von Bezing (2007) |
North Macedonia | |
| Ermolaeva et al. (2019) |
Norway | |
| Harald Folvik collection. |
Poland | |
| DOI: 10.1515/mipo-2016-0002 +2 other references |
| Siuda et al. (2013) |
| Domań +2 other references |
| Siuda et al. (2008) |
| Siuda et al. (2008) |
| Siuda et al. (2008) | |
| Siuda et al. (2008) |
| Eligiusz Szełęg collection |
| Siuda et al. (2008) |
Republic of the Congo | |
| Chris Emproto Collection |
Romania | |
| analyzed by Sándor Szakáll (XRD and EDS) |
Russia | |
| Pekov et al. (2025) |
| [World of Stones 12:49] | |
| American Mineralogist |
| Yarosh et al. (1953) +1 other reference | |
Slovakia | |
| Vlasáč et al. (2021) |
South Africa | |
| Cairncross et al. (1995) |
| Cairncross et al. (1995) |
| SAMS (South African Micromount Society) |
| Reeks (2007) |
Spain | |
| Calvo (2015) |
| Adrian Pesudo specimen | |
| Calvo (2015) | |
| José Miguel Sola Fernández and group. | |
| García Guirado (2016) |
| Carmona Ruiz +2 other references |
| Carmona Ruiz +2 other references | |
| Carmona Ruiz +3 other references | |
| Calvo Rebollar (2015) |
| Joan Abella i Creus (2008) |
| Rosell et al. (2017) |
| Jiménez Martínez |
| Tánago et al. (2012) |
| Gonzalez Del Tanago +3 other references |
| Calvo (2015) | |
| Calvo (2015) | |
| Sainz de Baranda Graf et al. (2023) |
| Sainz de Baranda Graf et al. (2023) |
Sweden | |
| Lyckberg (2006) |
Switzerland | |
| Stalder et al. (1998) |
| Ansermet (2012) |
| [var: Duhamelite] Stalder et al. (1998) | |
| Meisser (2012) |
UK | |
| Roscoe (1877) |
| Roscoe (1877) +1 other reference |
| Day (1999) | |
| Elton et al. (2004) |
| British Micromount Newletter No 19 ... +1 other reference |
| Golley et al. (1995) |
| Green et al. (2009) |
| Cooper et al. (1990) | |
| Kingsbury et al. (1956) +3 other references | |
| - (2006) | |
| - (2006) |
| Green et al. (2008) | |
| BM (NH) | |
| Bridges et al. (2008) | |
| Cooper et al. (1990) +1 other reference | |
| Stanley et al. (1991) | |
| BMS Collection +2 other references |
| Kingsbury et al. (1956) +3 other references | |
| Day (1999) +2 other references |
| Hubbard et al. (2005) +2 other references |
| Day (1999) |
| [Specimen in the Natural History Museum +4 other references |
| |
| |
| www.mindat.org (2023) +1 other reference | |
| |
| S Rust collection | |
| S Rust collection | |
| S Rust collection | |
| [BMS] |
| Parnell et al. (2016) |
| |
| S Rust collection |
| |
| Day (1999) | |
| Neall (2005) | |
USA | |
| Anthony et al. (1995) |
| Graeme (1993) +1 other reference | |
| Taber et al. (1930) +3 other references | |
| Taber et al. (1930) +2 other references | |
| [var: Duhamelite] Anthony et al. (1995) |
| Ron Layton self collected | |
| Luetcke (n.d.) |
| Cooper (1964) +1 other reference | |
| Luetcke (n.d.) |
| [var: Duhamelite] Anthony et al. (1995) |
| [var: Duhamelite] Anthony et al. (1995) |
| Galbraith (1959) |
| Luetcke (n.d.) |
| Ronald C. Render | |
| Anthony et al. (1995) | |
| Guild (1911) +2 other references | |
| Rob Bowell | |
| Raman identification by Dr. Yang | |
| Marek Chorazewicz (2023) |
| Luetcke (n.d.) | |
| Guild (1911) |
| Luetcke (n.d.) |
| Robert Jenkins Raman Spectroscopy |
| Keith (1972) +1 other reference |
| Eastlick | |
| Peterson (1962) |
| Rocks & Minerals (1945) +5 other references |
| [var: Duhamelite] Luetcke (n.d.) |
| [var: Duhamelite] Williams (1981) +1 other reference |
| [var: Duhamelite] Anthony et al. (1995) |
| Francis Sousa |
| Anthony et al. (1995) |
| Kampf et al. (2019) +1 other reference | |
| [var: Duhamelite] Ron Gibbs |
| Theodore et al. (1987) |
| Joe Marty personal communication |
| Thomas et al. (1983) |
| Gilluly (1937) +2 other references | |
| Williams et al. (1963) +1 other reference |
| Williams et al. (1963) +1 other reference | |
| Rocks & Min.: 65: 29. +2 other references |
| Luetcke (n.d.) |
| Luetcke (n.d.) |
| Collected by Mark Ascher Sight ... |
| Galbraith (1947) |
| Guild (1910) +4 other references |
| |
| Luetcke (n.d.) | |
| Guild (1911) +3 other references |
| MRDS database Dep. ID #10092560 |
| Headden (1903) +4 other references |
| Galbraith (1959) |
| Anthony et al. (1995) |
| M Massis |
| [var: Duhamelite] Bob Meyer (2012) |
| [var: Duhamelite] Collected by Joe Ruiz. | |
| Scovil et al. (1991) +1 other reference |
| Anthony et al. (1995) |
| Josh Varnedore Collection |
| Eckhard D. Stuart - collection |
| [var: Duhamelite] Walstrom (n.d.) |
| Walstrom (n.d.) |
| Adams (2010) +1 other reference |
| Housley |
| Lavinsky (n.d.) |
| |
| Dunning et al. (2005) |
| Murdoch (1966) +1 other reference |
| Dr. Robert Housley |
| Reynolds R. E. (2002) +2 other references |
| R.M. Housley and R.E. Reynolds (2002) | |
| MarekC collection 2019 |
| MarekC Collection (2017) |
| Schaller (1911f) +2 other references |
| Schaller (1911f) +2 other references |
| Kampf et al. (2010) |
| Joe Marty specimens +1 other reference | |
| Joe Marty specimens | |
| MarekC personal collection | |
| in the collection of Eckhard D. Stuart | |
| Housley R. | |
| Collected by and in the collection of ... +1 other reference |
| Collected by and in the collection of ... +1 other reference | |
| - (2005) |
| Carlson et al. (2007) |
| Betts (n.d.) |
| Tucker (n.d.) +1 other reference |
| Tucker (n.d.) +1 other reference |
| Palache et al. (1951) |
| Schilling (1979) +1 other reference |
| Castor et al. (2004) +1 other reference | |
| Rocks & Minerals. Nov. 1999. |
| USGS Bul 1010 Geologic Controls of Lead ... | |
| Castor et al. (2004) | |
| [var: Duhamelite] Self collected by Brent Thorne. SEM ... +1 other reference | |
| Castor et al. (2004) | |
| Haynes (2007) | |
| Castor et al. (2004) | |
| Castor et al. (2004) | |
| Castor et al. (2004) |
| Castor et al. (2004) | |
| Dr. William S. Wise presentation to ... |
| Castor et al. (2004) |
| [var: Duhamelite] Walstrom +1 other reference |
| NBMG Bull 10 |
| NBMG Bull 10 | |
| Martin Jensen (2011) |
| Castor et al. (2004) |
| Castor et al. (2004) |
| Castor et al. (2004) |
| Castor et al. (2004) |
| Castor et al. (2004) |
| Castor et al. (2004) |
| Castor et al. (2004) | |
| Northrop et al. (1996) |
| Northrop et al. (1996) |
| Northrop et al. (1996) | |
| D.Court collection | |
| Jerry Cone Collection |
| Northrop et al. (1996) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Northrop et al. (1996) | |
| Lasky (1947) +1 other reference | |
| Jay Penn collection |
| Northrop et al. (1996) | |
| 2008 New Mexico Mineral Symposium ... |
| 2008 New Mexico Mineral Symposium ... | |
| 2008 New Mexico Mineral Symposium ... | |
| 2008 New Mexico Mineral Symposium ... |
| DeMark (2004) |
| Min News 20:10 p 8 +1 other reference | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| R&M 77:5 p298-305 |
| [var: Duhamelite] Walstrom (n.d.) |
| Northrop et al. (1996) |
| Chester S. Lemanski |
| 2009 New Mexico Mineral Symposium ... | |
| 2009 New Mexico Mineral Symposium ... +1 other reference | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| 2009 New Mexico Mineral Symposium ... | |
| 2009 New Mexico Mineral Symposium ... | |
| Min News 20:6 p8 |
| Northrop et al. (1996) | |
| Walstrom (n.d.) |
| Northrop et al. (1996) | |
| Lasky (1947) +1 other reference |
| Northrop et al. (1996) |
| NMBMGMR Open-file Report - 532 | |
| R&M 71:1 p66-68 |
| Anthony et al. (2000) | |
| Patrick Haynes. Self collected from the ... | |
| Walstrom (n.d.) |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom (n.d.) |
| Walstrom (n.d.) | |
| Walstrom (n.d.) | |
| Walstrom 2006 New Mexico Mineral ... |
| Walstrom (n.d.) | |
| Robert E. Wastrom Collection | |
| Northrop et al. (1996) |
| Northrop et al. (1996) |
| Jerry Cone Collection | |
| Alan Heyl |
| Northrop et al. (1996) | |
| Northrop et al. (1996) | |
| Jerry Cone Collection |
| [var: Duhamelite] Jerry Cone Collection | |
| Jerry Cone Collection | |
| Jerry Cone Collection | |
| Northrop et al. (1996) | |
| Northrop et al. (1996) |
| Northrop et al. (1996) | |
| Northrop et al. (1996) | |
| Northrop et al. (1996) | |
| Northrop et al. (1996) |
| Northrop et al. (1996) | |
| Northrop et al. (1996) | |
| M Massis collection |
| Alexander Wong Collection (collected by Mark T. Massis in 1997) | |
| M Massis collection |
| Northrop et al. (1996) | |
| Northrop et al. (1996) | |
| Min News 21:7 p 12 |
| Collected by and in collection of Jay ... | |
| Betts (n.d.) | |
| 4th Annual New Mexico Mineral Symposium (1985) +1 other reference |
| Sloto (1989) |
| Rocks & Min.: 60:111. |
| Smith (1991) |
| Smith (1991) | |
| Smith (1991) | |
| Smith (1991) | |
| Alminas +2 other references | |
| Barton et al. (2018) | |
| MarekC (2019) |
| Bullock (1981) |
| Contributions to Economic Geology |
| Kearns +1 other reference |
| USA Micro Probe +2 other references |
Uzbekistan | |
| Pavel M. Kartashov analytical data |
Zambia | |
| Palache et al. (1951) +1 other reference |
Quick NavTopAbout MottramiteUnique IdentifiersIMA Classification Classification Mineral SymbolsPhysical Properties Optical Data Chemistry Crystallography Crystal StructureX-Ray Powder DiffractionGeological EnvironmentType Occurrence SynonymsOther LanguagesVarietiesRelationshipsCommon AssociatesStrunz-MindatOther InformationInternet Links References Localities Locality List
Grangers shaft, Mottram St Andrew, Cheshire, England, UK
