Kraisslite
A valid IMA mineral species
This page is currently not sponsored. Click here to sponsor this page.
About Kraisslite
Alice and Fred Kraissl
Formula:
Zn3(Mn,Mg)25(Fe3+,Al)(As3+O3)2[(Si,As5+)O4]10(OH)16
The Zn is tetrahedrally coordinated. The mineral was formerly thought to have the formula (Mn2+,Mg)24Zn4(SiO4)8(AsO4)4(OH)12.
Colour:
Pale red-brown, deep coppery brown
Lustre:
Pearly
Hardness:
3 - 4
Specific Gravity:
3.876
Crystal System:
Orthorhombic
Member of:
Name:
Named in honor of Alice and Frederick Kraissl, North Hackensack, New Jersey, avid collectors of Franklin, NJ, minerals, former officers of the Franklin-Ogdensburg Mineralogical Society and generous benefactors to the Franklin Mineral Museum. Alice Louise Plenty Kraissl [May 5, 1905 - September 16, 1986 River Edge, New Jersey, USA], earned a bachelors degree in engineering from Barnard College in 1925, and co-founded the family business, Kraissl Associates, with her husband. She was an avid micro-mounter as well and made many discoveries of Franklin-Ogdensburg minerals, including jarosewichite, flinkite, and several species still unnamed. Frederick Kraissl, Jr. [July 8, 1899 New York, New York, USA - November 30, 1986 River Edge, New jersey, USA] was the son of a Croatian immigrant. He earned his masters degree in chemical engineering at Columbia University, New York in 1922 and his PhD, also from Columbia, for his thesis on "The Mechanics of Colors in Gems and Minerals." He was a Practicing Engineer (PE), specializing in the manufacture of glass.
This page provides mineralogical data about Kraisslite.
Unique Identifiers
Mindat ID:
2268
Long-form identifier:
mindat:1:1:2268:8
Similar Names
| Krieselite | A valid IMA mineral species | Al2(GeO4)F2 |
IMA Classification of Kraisslite
Approved
Approval year:
1977
First published:
1978
Classification of Kraisslite
8.BE.45
8 : PHOSPHATES, ARSENATES, VANADATES
B : Phosphates, etc., with additional anions, without H2O
E : With only medium-sized cations, (OH, etc.):RO4 > 2:1
8 : PHOSPHATES, ARSENATES, VANADATES
B : Phosphates, etc., with additional anions, without H2O
E : With only medium-sized cations, (OH, etc.):RO4 > 2:1
43.4.10.1
43 : COMPOUND PHOSPHATES, ETC.
4 : Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or Halogen
43 : COMPOUND PHOSPHATES, ETC.
4 : Anhydrous Compound Phosphates, etc·, Containing Hydroxyl or Halogen
17.7.11
17 : Silicates Containing other Anions
7 : Silicates with vanadate, arsenate or antimonate
17 : Silicates Containing other Anions
7 : Silicates with vanadate, arsenate or antimonate
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference for Standard |
|---|---|---|
| Ksl | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Physical Properties of Kraisslite
Pearly
Transparency:
Transparent, Translucent
Colour:
Pale red-brown, deep coppery brown
Streak:
Golden brown
Hardness:
3 - 4 on Mohs scale
Tenacity:
Brittle
Cleavage:
Perfect
{0001}
{0001}
Density:
3.876 g/cm3 (Measured) 3.903 g/cm3 (Calculated)
Optical Data of Kraisslite
Type:
Uniaxial (+)
RI values:
nε = 1.805
Max. Birefringence:
δ = 0.000
Based on recorded range of RI values above.
Based on recorded range of RI values above.
Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
Surface Relief:
Moderate
Colour in reflected light:
coppery
Chemistry of Kraisslite
Mindat Formula:
Zn3(Mn,Mg)25(Fe3+,Al)(As3+O3)2[(Si,As5+)O4]10(OH)16
The Zn is tetrahedrally coordinated. The mineral was formerly thought to have the formula (Mn2+,Mg)24Zn4(SiO4)8(AsO4)4(OH)12.
The Zn is tetrahedrally coordinated. The mineral was formerly thought to have the formula (Mn2+,Mg)24Zn4(SiO4)8(AsO4)4(OH)12.
Element Weights:
Common Impurities:
Al,H2O
Crystallography of Kraisslite
Crystal System:
Orthorhombic
Class (H-M):
2 2 2 - Disphenoidal
Space Group:
C2 2 21
Cell Parameters:
a = 8.1821(1) Å, b = 14.1946(3) Å, c = 43.9103(8) Å
Ratio:
a:b:c = 0.576 : 1 : 3.093
Unit Cell V:
5099.8 ų
Z:
4
Comment:
Formerly thought to be hexagonal, a = 8.22, c = 43.88 A.
Crystal Structure
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File Best | x | y | z | a | b | c
CIF File Best | x | y | z | a | b | c
Rotation
Stop | Start
Stop | Start
Labels
Console Off | On | Grey | Yellow
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0019752 | Kraisslite | Cooper M A, Hawthorne F C (2012) Crystal structure of kraisslite, Zn3(Mn,Mg)25(Fe3+,Al)(As3+O3)2[(Si,As5+)O4]10(OH)16, from the Sterling Hill mine, Ogdensburg, Sussex County, New Jersey, USA Mineralogical Magazine 76 2819-2836 | 2012 | the Sterling Hill mine, Ogdensburg, Sussex County, New Jersey, USA | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder Diffraction
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 10.9 Å | (6) |
| 7.27 Å | (1) |
| 4.385 Å | (45) |
| 3.651 Å | (35) |
| 3.130 Å | (20) |
| 2.993 Å | (2) |
| 2.740 Å | (100) |
| 2.437 Å | (55) |
| 2.194 Å | (55) |
| 1.4601 Å | (1) |
| 1.2907 Å | (2) |
| 1.2190 Å | (7) |
| 1.1552 Å | (2) |
Reference:
Comments:
ICDD 29-1432
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| High-? alteration and/or metamorphism | |
| 32 : Ba/Mn/Pb/Zn deposits, including metamorphic deposits | |
| 33 : Minerals deposited by hydrothermal metal-rich fluids (see also [#12]) |
Type Occurrence of Kraisslite
General Appearance of Type Material:
Films and lenses to one inch thick
Place of Conservation of Type Material:
National Museum of Natural History, Washington, D.C., USA, 137017, 137018.
Geological Setting of Type Material:
1010 Stope central zincite zone.
Associated Minerals at Type Locality:
Synonyms of Kraisslite
Other Language Names for Kraisslite
Relationship of Kraisslite to other Species
Member of:
Other Members of Hematolite Group:
| Arakiite | (Zn,Mn2+)(Mn2+,Mg)12(Fe3+,Al)2(As5+O4)2(As3+O3)(OH)23 | Mon. m : Bb |
| Dixenite | CuMn2+14Fe2+(SiO4)2(As5+O4)(As3+O3)5(OH)6 | Trig. 3 : R3 |
| Hematolite | (Mn,Mg,Al,Fe3+)15(As5+O4)2(As3+O3)(OH)23 | Trig. 3 : R3 |
| Mcgovernite | Mn19Zn3(AsO4)3(AsO3)(SiO4)3(OH)21 | Trig. 3m : R3c |
| Synadelphite | Mn2+9(As5+O4)2(As3+O3)(OH)9 · 2H2O | Orth. mmm (2/m 2/m 2/m) : Pnma |
| Turtmannite | (Mn,Mg)22.5Mg3-3x((V5+,As5+)O4)3(As3+O3)x(SiO4)3O5-5x(OH)20+x | Trig. |
Common Associates
Associations Based on Photo Data:
| 28 photos of Kraisslite associated with Willemite | Zn2SiO4 |
| 27 photos of Kraisslite associated with Franklinite | Zn2+Fe3+2O4 |
| 8 photos of Kraisslite associated with Calcite | CaCO3 |
| 8 photos of Kraisslite associated with Zincite | ZnO |
| 7 photos of Kraisslite associated with Holdenite | (Mn2+,Mg)6Zn3(AsO4)2(SiO4)(OH)8 |
| 5 photos of Kraisslite associated with Eveite | Mn2+2(AsO4)(OH) |
| 5 photos of Kraisslite associated with Chlorophoenicite | (Mn,Mg)3Zn2(AsO4)(OH,O)6 |
| 4 photos of Kraisslite associated with Sarkinite | Mn2+2(AsO4)(OH) |
| 4 photos of Kraisslite associated with Sussexite | Mn2+BO2(OH) |
| 4 photos of Kraisslite associated with Akrochordite | MnMn2Mn2(AsO4)2(OH)4(H2O)4 |
Related Minerals - Strunz-mindat Grouping
| 8.BE.05 | Augelite | Al2(PO4)(OH)3 |
| 8.BE.10 | Grattarolaite | Fe3+3(PO4)O3 |
| 8.BE.15 | Cornetite | Cu3(PO4)(OH)3 |
| 8.BE.20 | Clinoclase | Cu3(AsO4)(OH)3 |
| 8.BE.25 | Gilmarite | Cu3(AsO4)(OH)3 |
| 8.BE.25 | Arhbarite | Cu2Mg(AsO4)(OH)3 |
| 8.BE.30 | Flinkite | Mn2+2Mn3+(AsO4)(OH)4 |
| 8.BE.30 | Argandite | Mn7(VO4)2(OH)8 |
| 8.BE.30 | Raadeite | Mg7(PO4)2(OH)8 |
| 8.BE.30 | Allactite | Mn2+7(AsO4)2(OH)8 |
| 8.BE.35 | 'Mineral E (of Dunn, et. al., 1982)' | |
| 8.BE.35 | Chlorophoenicite | (Mn,Mg)3Zn2(AsO4)(OH,O)6 |
| 8.BE.35 | Magnesiochlorophoenicite | (Mg,Mn)3Zn2(AsO4)(OH,O)6 |
| 8.BE.40 | Gerdtremmelite | (Zn,Fe)(Al,Fe)2(AsO4)(OH)5 |
| 8.BE.45 | Dixenite | CuMn2+14Fe2+(SiO4)2(As5+O4)(As3+O3)5(OH)6 |
| 8.BE.45 | Mcgovernite | Mn19Zn3(AsO4)3(AsO3)(SiO4)3(OH)21 |
| 8.BE.45 | Hematolite | (Mn,Mg,Al,Fe3+)15(As5+O4)2(As3+O3)(OH)23 |
| 8.BE.45 | Turtmannite | (Mn,Mg)22.5Mg3-3x((V5+,As5+)O4)3(As3+O3)x(SiO4)3O5-5x(OH)20+x |
| 8.BE.45 | Carlfrancisite | Mn2+3(Mn2+,Mg,Fe3+,Al)42[As3+O3]2(As5+O4)4[(Si,As5+)O4]6[(As5+,Si)O4]2(OH)42 |
| 8.BE.45 | Arakiite | (Zn,Mn2+)(Mn2+,Mg)12(Fe3+,Al)2(As5+O4)2(As3+O3)(OH)23 |
| 8.BE.50 | Synadelphite | Mn2+9(As5+O4)2(As3+O3)(OH)9 · 2H2O |
| 8.BE.55 | Holdenite | (Mn2+,Mg)6Zn3(AsO4)2(SiO4)(OH)8 |
| 8.BE.60 | Kolicite | Mn2+7Zn4(AsO4)2(SiO4)2(OH)8 |
| 8.BE.65 | Sabelliite | (Cu,Zn)2Zn(AsO4,SbO4)(OH)3 |
| 8.BE.70 | Jarosewichite | Mn2+3Mn3+(AsO4)(OH)6 |
| 8.BE.75 | Theisite | Cu5Zn5(AsO4,SbO4)2(OH)14 |
| 8.BE.80 | Coparsite | Cu4(AsO4,VO4)O2Cl |
| 8.BE.85 | Waterhouseite | Mn2+7(PO4)2(OH)8 |
| 8.BE.90 | Vasilseverginite | Cu9O4(AsO4)2(SO4)2 |
Fluorescence of Kraisslite
Not fluorescent in UV
Other Information
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for Kraisslite
mindat.org URL:
https://www.mindat.org/min-2268.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
Mineral Dealers:
References for Kraisslite
Localities for Kraisslite
Showing 1 localities.
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
USA (TL) | |
| Moore et al. (1978) +4 other references |
Quick NavTopAbout KraissliteUnique IdentifiersSimilar NamesIMA Classification Classification Mineral SymbolsPhysical Properties Optical Data Chemistry Crystallography Crystal StructureX-Ray Powder DiffractionGeological EnvironmentType Occurrence SynonymsOther LanguagesRelationshipsCommon AssociatesStrunz-MindatFluorescence Other InformationInternet Links References Localities Locality List
Sterling Mine, Sterling Hill, Ogdensburg, Sussex County, New Jersey, USA
