Chalcanthite
A valid IMA mineral species - grandfathered
This page is currently not sponsored. Click here to sponsor this page.
About Chalcanthite
Formula:
CuSO4 · 5H2O
Colour:
Green, green blue, light blue, or dark blue; colourless to pale blue in transmitted light.
Lustre:
Vitreous, Resinous
Hardness:
2½
Specific Gravity:
2.286
Crystal System:
Triclinic
Member of:
Name:
From the Greek chalkos, "copper" and anthos, "flower."
Chalcanthite Group.
Copper analogue of siderotil and pentahydrite.
Chalcanthite is natural, water-soluble copper sulphate pentahydrate. It is a secondary mineral that is formed in arid climates or in rapidly oxidizing copper deposits. It is usually of post-mining formation, forming on mine walls and by the action of acidic surface waters on veins of copper ore.
CAUTION: Many, usually well-crystallised chalcanthite specimens offered for sale (e.g. on-line auctions), are artificially grown.
Copper analogue of siderotil and pentahydrite.
Chalcanthite is natural, water-soluble copper sulphate pentahydrate. It is a secondary mineral that is formed in arid climates or in rapidly oxidizing copper deposits. It is usually of post-mining formation, forming on mine walls and by the action of acidic surface waters on veins of copper ore.
CAUTION: Many, usually well-crystallised chalcanthite specimens offered for sale (e.g. on-line auctions), are artificially grown.
Unique Identifiers
Mindat ID:
959
Long-form identifier:
mindat:1:1:959:3
IMA Classification of Chalcanthite
Approved, 'Grandfathered' (first described prior to 1959)
IMA Formula:
Cu(SO4) · 5H2O
Classification of Chalcanthite
7.CB.20
7 : SULFATES (selenates, tellurates, chromates, molybdates, wolframates)
C : Sulfates (selenates, etc.) without additional anions, with H2O
B : With only medium-sized cations
7 : SULFATES (selenates, tellurates, chromates, molybdates, wolframates)
C : Sulfates (selenates, etc.) without additional anions, with H2O
B : With only medium-sized cations
Dana 7th ed.:
29.6.7.1
29.6.7.1
29 : HYDRATED ACID AND NORMAL SULFATES
6 : AXO4·xH2O
29 : HYDRATED ACID AND NORMAL SULFATES
6 : AXO4·xH2O
25.2.3
25 : Sulphates
2 : Sulphates of Cu and Ag
25 : Sulphates
2 : Sulphates of Cu and Ag
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference |
|---|---|---|
| Cct | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Pronunciation of Chalcanthite
Pronunciation:
| Play | Recorded by | Country |
|---|---|---|
| Jolyon Ralph | United Kingdom |
Physical Properties of Chalcanthite
Vitreous, Resinous
Transparency:
Transparent, Translucent
Colour:
Green, green blue, light blue, or dark blue; colourless to pale blue in transmitted light.
Streak:
White
Hardness:
2½ on Mohs scale
Hardness Data:
Measured
Tenacity:
Brittle
Cleavage:
Imperfect/Fair
Imperfect on {110}, Indistinct on {111}; and, {110} in traces.
Imperfect on {110}, Indistinct on {111}; and, {110} in traces.
Parting:
None reported.
Fracture:
Conchoidal
Density:
2.286 g/cm3 (Measured) 2.282 g/cm3 (Calculated)
Comment:
Measured on artificial material.
Optical Data of Chalcanthite
Type:
Biaxial (-)
RI values:
nα = 1.514 nβ = 1.537 nγ = 1.543
2V:
Measured: 56° , Calculated: 56°
Max. Birefringence:
δ = 0.029
Based on recorded range of RI values above.
Based on recorded range of RI values above.
Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
Surface Relief:
Moderate
Dispersion:
r < v
Chemistry of Chalcanthite
Mindat Formula:
CuSO4 · 5H2O
Element Weights:
Elements listed:
CAS Registry number:
Common Impurities:
Fe,Mg,Co
Crystallography of Chalcanthite
Crystal System:
Triclinic
Class (H-M):
1 - Pinacoidal
Space Group:
P1
Cell Parameters:
a = 6.11 Å, b = 10.673 Å, c = 5.95 Å
α = 97.58°, β = 107.17°, γ = 77.55°
α = 97.58°, β = 107.17°, γ = 77.55°
Ratio:
a:b:c = 0.572 : 1 : 0.557
Unit Cell V:
361.03 ų (Calculated from Unit Cell)
Z:
2
Morphology:
Crystal short prismatic {001} or less commonly tabular {111}. Natural crystals rather rare. Commonly found as stalactic material, massive, granular filling veins (cross-fiber veinlets) and as crusts.
Twinning:
Rarely forms cruciform twins, with the edges [001] and [100] on one crystal respectively parallel to [100] and [001] on the other, and with {010} in common.
Comment:
Non-standard unit cell.
Crystal Structure
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File Best | x | y | z | a | b | c
CIF File Best | x | y | z | a | b | c
Rotation
Stop | Start
Stop | Start
Labels
Console Off | On | Grey | Yellow
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0010779 | Chalcanthite | Bacon G E, Titterton D H (1975) Neutron-diffraction studies of CuSO4*5(H2O) and CuSO4*5(D2O) Zeitschrift fur Kristallographie 141 330-341 |  | 1975 | 0 | 293 | |
| 0010780 | Chalcanthite | Bacon G E, Titterton D H (1975) Neutron-diffraction studies of CuSO4*5(H2O) and CuSO4*5(D2O) Zeitschrift fur Kristallographie 141 330-341 | | 1975 | 0 | 293 | |
| 0017438 | Chalcanthite | Beevers C, Lipson H (1934) The crystal structure of copper sulfate pentahydrate CuSO4(H2O)5 _cod_database_code 1010527 Proceedings of the Royal Society of London A146 570-582 | 1934 | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder Diffraction
Loading XRD data...
Data courtesy of RRUFF project at University of Arizona, used with permission.
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 5.48 Å | (60) |
| 4.73 Å | (100) |
| 3.99 Å | (60) |
| 3.71 Å | (90) |
| 3.30 Å | (60) |
| 2.82 Å | (40) |
| 2.75 Å | (50) |
| 2.66 Å | (40) |
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| Stage 7: Great Oxidation Event | <2.4 |
| 45a : [Sulfates, arsenates, selenates, antimonates] | |
| 45b : [Other oxidized fumarolic minerals] | |
| 47a : [Near-surface hydration of prior minerals] | |
| 47b : [Sulfates and sulfites] | |
| Stage 10a: Neoproterozoic oxygenation/terrestrial biosphere | <0.6 |
| 50 : Coal and/or oil shale minerals | <0.36 |
| Stage 10b: Anthropogenic minerals | <10 Ka |
| 54 : Coal and other mine fire minerals (see also #51 and #56) | |
| 55 : Anthropogenic mine minerals |
Geological Setting:
Found in the oxidized zones of copper deposits, usually in arid regions where it is not dissolved by ground water. Commonly associated with other hydrated sulphates of Cu or Fe.
Type Occurrence of Chalcanthite
Synonyms of Chalcanthite
Other Language Names for Chalcanthite
Basque:Kalkantita
Catalan:Calcantita
Czech:Chalkantit
Dutch:Chalcanthiet
Galician:Calcantita
Hungarian:Kalkantit
Italian:Calcantite
Vitriolo di Rame
Vitriolo di Rame
Japanese:胆礬
Polish:Chalkantyt
Portuguese:Calcantite
Russian:Халькантит
Simplified Chinese:胆矾
Slovak:Chalkantit
Ukrainian:Халькантит
Varieties of Chalcanthite
| Phillipite | Probably an impure Fe-bearing chalcanthite. |
| zinc-magnesia chalcanthite | zinc-magnesium bearing chalcanthite |
Relationship of Chalcanthite to other Species
Member of:
Other Members of Chalcanthite Group:
| Belogubite | CuZn(SO4)2 · 10H2O | Tric. 1 : P1 |
| Jôkokuite | MnSO4 · 5H2O | Tric. 1 : P1 |
| Pentahydrite | MgSO4 · 5H2O | Tric. 1 : P1 |
| Siderotil | FeSO4 · 5H2O | Tric. |
Common Associates
Associated Minerals Based on Photo Data:
| 40 photos of Chalcanthite associated with Coquimbite | AlFe3(SO4)6(H2O)12 · 6H2O |
| 34 photos of Chalcanthite associated with Copiapite | Fe2+Fe3+4(SO4)6(OH)2 · 20H2O |
| 32 photos of Chalcanthite associated with Alunogen | Al2(SO4)3 · 17H2O |
| 24 photos of Chalcanthite associated with Halotrichite | FeAl2(SO4)4 · 22H2O |
| 24 photos of Chalcanthite associated with Amarantite | Fe3+2(SO4)2O · 7H2O |
| 24 photos of Chalcanthite associated with Johannite | Cu(UO2)2(SO4)2(OH)2 · 8H2O |
| 23 photos of Chalcanthite associated with Quartz | SiO2 |
| 20 photos of Chalcanthite associated with Römerite | Fe2+Fe3+2(SO4)4 · 14H2O |
| 19 photos of Chalcanthite associated with Calcite | CaCO3 |
| 19 photos of Chalcanthite associated with Melanterite | Fe2+(H2O)6SO4 · H2O |
Related Minerals - Strunz-mindat Grouping
| 7.CB. | Sarvodaite | Al2(SO4)3 · 5H2O |
| 7.CB.02 | Voudourisite | CdSO4 · H2O |
| 7.CB.05 | Szmikite | MnSO4 · H2O |
| 7.CB.05 | Szomolnokite | FeSO4 · H2O |
| 7.CB.05 | Cobaltkieserite | CoSO4 · H2O |
| 7.CB.05 | Dwornikite | Ni(SO4) · H2O |
| 7.CB.05 | Kieserite | MgSO4 · H2O |
| 7.CB.05 | Poitevinite | (Cu,Fe)SO4 · H2O |
| 7.CB.05 | Gunningite | ZnSO4 · H2O |
| 7.CB.07 | Sanderite | MgSO4 · 2H2O |
| 7.CB.10 | Bonattite | CuSO4 · 3H2O |
| 7.CB.12 | Belogubite | CuZn(SO4)2 · 10H2O |
| 7.CB.15 | Drobecite | CdSO4 · 4H2O |
| 7.CB.15 | Aplowite | (Co,Mn,Ni)SO4 · 4H2O |
| 7.CB.15 | Cranswickite | MgSO4 · 4H2O |
| 7.CB.15 | Rozenite | FeSO4 · 4H2O |
| 7.CB.15 | Starkeyite | MgSO4 · 4H2O |
| 7.CB.15 | Ilesite | Mn2+(SO4) · 4H2O |
| 7.CB.15 | Boyleite | ZnSO4 · 4H2O |
| 7.CB.20 | Siderotil | FeSO4 · 5H2O |
| 7.CB.20 | Jôkokuite | MnSO4 · 5H2O |
| 7.CB.20 | Pentahydrite | MgSO4 · 5H2O |
| 7.CB.25 | Chvaleticeite | Mn(SO4) · 6H2O |
| 7.CB.25 | Nickelhexahydrite | Ni(SO4) · 6H2O |
| 7.CB.25 | Hexahydrite | MgSO4 · 6H2O |
| 7.CB.25 | Bianchite | Zn(SO4) · 6H2O |
| 7.CB.25 | Moorhouseite | Co(SO4) · 6H2O |
| 7.CB.25 | Ferrohexahydrite | FeSO4 · 6H2O |
| 7.CB.30 | Retgersite | NiSO4 · 6H2O |
| 7.CB.35 | Zincmelanterite | (Zn,Cu,Fe)SO4 · 7H2O |
| 7.CB.35 | Melanterite | Fe2+(H2O)6SO4 · H2O |
| 7.CB.35 | Alpersite | (Mg,Cu)(SO4) · 7H2O |
| 7.CB.35 | Bieberite | CoSO4 · 7H2O |
| 7.CB.35 | Boothite | CuSO4 · 7H2O |
| 7.CB.35 | Mallardite | MnSO4 · 7H2O |
| 7.CB.40 | Epsomite | MgSO4 · 7H2O |
| 7.CB.40 | Goslarite | ZnSO4 · 7H2O |
| 7.CB.40 | Morenosite | NiSO4 · 7H2O |
| 7.CB.45 | Meta-alunogen | Al2(SO4)3 · 12H2O |
| 7.CB.45 | Alunogen | Al2(SO4)3 · 17H2O |
| 7.CB.50 | Aluminocoquimbite | Al2Fe2(SO4)6(H2O)12 · 6H2O |
| 7.CB.50 | Lazaridisite | 3CdSO4 · 8H2O |
| 7.CB.52 | Pararaisaite | CuMg[Te6+O4(OH)2] · 6H2O |
| 7.CB.55 | Paracoquimbite | Fe4(SO4)6(H2O)12 · 6H2O |
| 7.CB.55 | Rhomboclase | (H5O2)Fe3+(SO4)2 · 2H2O |
| 7.CB.55 | Raisaite | CuMg[Te6+O4(OH)2] · 6H2O |
| 7.CB.55 | Coquimbite | AlFe3(SO4)6(H2O)12 · 6H2O |
| 7.CB.57 | Caichengyunite | Fe2+3Al2(SO4)6 · 30H2O |
| 7.CB.60 | Kornelite | Fe2(SO4)3 · 7H2O |
| 7.CB.65 | Quenstedtite | Fe2(SO4)3 · 11H2O |
| 7.CB.70 | Lausenite | Fe2(SO4)3 · 5H2O |
| 7.CB.75 | Römerite | Fe2+Fe3+2(SO4)4 · 14H2O |
| 7.CB.75 | Lishizhenite | ZnFe2(SO4)4 · 14H2O |
| 7.CB.80 | Ransomite | CuFe2(SO4)4 · 6H2O |
| 7.CB.85 | Dietrichite | (Zn,Fe2+,Mn2+)Al2(SO4)4 · 22H2O |
| 7.CB.85 | Halotrichite | FeAl2(SO4)4 · 22H2O |
| 7.CB.85 | Apjohnite | Mn2+Al2(SO4)4 · 22H2O |
| 7.CB.85 | Redingtonite | (Fe2+,Mg,Ni)(Cr,Al)2(SO4)4 · 22H2O |
| 7.CB.85 | Pickeringite | MgAl2(SO4)4 · 22H2O |
| 7.CB.85 | Bílinite | Fe2+Fe3+2(SO4)4 · 22H2O |
| 7.CB.85 | Wupatkiite | (Co,Mg,Ni)Al2(SO4)4 · 22H2O |
| 7.CB.90 | Meridianiite | MgSO4 · 11H2O |
Other Information
Notes:
Soluble in water. Dehydrates in dry air forming lighter powder.
Health Risks:
Hazardous in case of skin contact (irritant), of eye contact (irritant), of ingestion, of inhalation. Acute oral toxicity (LD50): 300 mg/kg [Rat.].
Industrial Uses:
On occasion, it is found in sufficient volume to be mined as an ore of copper.
Internet Links for Chalcanthite
mindat.org URL:
https://www.mindat.org/min-959.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
References for Chalcanthite
Reference List:
Beudant, F. S. (1832) Traité élémentaire de minéralogie (2nd ed.) Vol. 2. Chez Verdière. pp.486-486
von Kobell, Franz [Franz Wolffgang Kobel] (1853) Die Mineral-Namen und die mineralogische Nomenklatur. J.G. Cotta'schen Buchhandlung. p.80
Collins, Henry F. (1923) On some crystallized sulphates from the province of Huelva, Spain. Mineralogical Magazine and Journal of the Mineralogical Society, 20 (100). 32-38 doi:10.1180/minmag.1923.020.100.05
Ungemach, Henri (1935) Sur certains minéraux sulfatés du Chili. Bulletin de Minéralogie, 58 (3) 97-221 doi:10.3406/bulmi.1935.4369
Bandy, Mark C. (1938) Mineralogy of three sulphate deposits of northern Chile. American Mineralogist, 23 (11) 669-760 p.718
Ibrahim, Mukaila A., Boeré, René T. (2022) The copper sulfate hydration cycle. Crystal structures of CuSO4 (Chalcocyanite), CuSO4·H2O (Poitevinite), CuSO4·3H2O (Bonattite) and CuSO4·5H2O (Chalcanthite) at low temperature using non-spherical atomic scattering factors. New Journal of Chemistry, 46 (12) 5479-5488 doi:10.1039/d2nj00169a
Localities for Chalcanthite
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
Afghanistan | |
| Orris et al. (2002) |
Antarctica | |
| Vennum +1 other reference |
Argentina | |
| Raúl Jorge Tauber Larry |
| Brodtkorb (2002) | |
| Dina (1993) |
| 4 Congreso Nacional y 1 Congreso ... +1 other reference |
| Brodtkorb et al. (1999) |
| Brotkorb (2002) | |
| American Mineralogist: 51: 1-13 |
| Brodtkorb (2002) |
| Perelló et al. (2023) |
Atlantic Ocean | |
| Maslennikov et al. (2023) |
| Meng et al. (2021) |
| Dang et al. (2024) | |
Australia | |
| Gilligan et al. (1993) |
| Chapman et al. (2005) |
| Gilligan et al. (1992) |
| Gilligan et al. (1992) |
| Slansky (1983) +1 other reference |
| Henley et al. (2001) |
| Henley et al. (2001) | |
| Henley et al. (2001) |
| Keith Compton collection (self collected) |
| Leverett et al. (2007) |
| Henley et al. (2001) |
| Ashley et al. (1999) |
| Sorrell (n.d.) |
| Gilligan et al. (1993) | |
| Sorrell (n.d.) | |
| Gilligan et al. (1993) | |
| Gilligan et al. (1993) | |
| Sorrell (n.d.) |
| Gilligan et al. (1993) |
| Ashley et al. (1999) |
| JR Chapman - Geological Survey of NSW ... |
| Leverett et al. (2005) |
| Leverett et al. (2005) | |
| Gilligan et al. (1992) |
| Gilligan et al. (1992) |
| Birch et al. (1997) |
| Birch et al. (1997) |
| Warren (1980) |
| Thienenkamp (2004) |
| Sielecki (1988) +1 other reference |
| Sielecki (1988) | |
| Queensland Government Department of ... |
| Harris et al. (2003) |
| Brown (1908) |
| |
| |
| Pring (1988) |
| Beyer et al. (1996) |
| Pring et al. (1994) |
| Francis et al. (self published) |
| National Museum of Australia Collection ... |
| Minerals from Bundaleer and the ... |
| Coats et al. (1971) |
| |
| Francis (2010) |
| Francis (2010) |
| |
| Bottrill et al. (2008) |
| Bottrill et al. (2008) |
| www.crocoite.com (2004) |
| www.crocoite.com (2004) |
| Bottrill & Taheri |
| Bottrill +1 other reference |
| Bottrill (2000) +1 other reference |
| Bottrill et al. (2008) | |
| Bottrill |
| Sorrell (n.d.) |
| crocoite.com |
| WILKINSON (1971) |
| Judy Rowe collection |
| |
| Marshall (2001) |
| Downes et al. (1998) +1 other reference |
| Marston (1979) |
| Simpson Mineral Collection of the ... +1 other reference |
| Sharon Cisneros collection | |
Austria | |
| C.Auer (2014) |
| Kolitsch (2009) |
| C.Auer (2017) | |
| Niedermayr et al. (1995) |
| Niedermayr et al. (1995) |
| Kolitsch et al. (2013) |
| Blaß et al. (1997) |
| Meixner (1976) |
| Pichler (2003) | |
| Niedermayr et al. (1995) |
| G.Blaß |
| C. Auer (2022) |
| G. Niedermayr: Carinthia II 187./107.:174 (1997) |
| Niedermayr et al. (1995) |
| Niedermayr et al. (1995) |
| Stütz (1807) +2 other references |
| Stütz (1807) |
| Meixner (1976) |
| Strasser (1989) | |
| Ertl et al. (2025) |
| Strasser (1989) |
| Strasser (1989) |
| Strasser (1989) |
| Strasser (1989) |
| Lewandowski et al. (2006) |
| Strasser (1989) |
| Landesmuseum Joanneum (Graz, Styria) |
| Neschen (n.d.) +1 other reference |
| Collection Daniel Lunau +1 other reference |
| Kolitsch (2018) |
| Taucher et al. (1995) |
| Postl (1977) | |
| Schnorrer et al. (2005) |
| Schnorrer+Poeverlein (2005) | |
| - (1994, July) |
| Meixner (1976) |
| Kolitsch (2014) |
| Kolitsch et al. (2022) | |
Azerbaijan | |
| - (2005) +1 other reference |
Bolivia | |
| Collections of Alfredo Petrov and Dr. ... |
| Geology and Mineral Resources of the Altiplano and Cordillera Occidental (USGS Bulletin no. 1975) +1 other reference |
| Petrov (n.d.) |
| Wilson (2001) +1 other reference |
| Brian Kosnar specimen |
| Alfredo Petrov field collected specimens (visual ID) +1 other reference |
| Salomon Rivas y Federico Ahlfeld (1998) |
| Smith et al. (2001) +1 other reference |
| Salomon Rivas y Federico Ahlfeld (1998) |
Bulgaria | |
| Lips (2006) |
| Singer et al. (2008) +1 other reference |
| Singer et al. (2008) | |
| Atanassova et al. (2009) |
Canada | |
| Färber (n.d.) |
| the world's largest besshi-type ... +1 other reference | |
| Geological Association of Canada (2014) |
| Sabina (1967) |
| Sabina (2003) |
| Sabina (2003) | |
| SABINA (1976) | |
| Transactions of the Canadian Institute ... +1 other reference |
| Gait et al. (1990) |
| Rainer Mielke collection (SXRD-analysis Uwe Kolitsch) +1 other reference |
| Sabina (1991) |
| 157-158. +1 other reference |
| Sabina (2003) +1 other reference |
| Singer et al. (2008) |
Chile | |
| Cameron et al. (2007) |
| Collected by myself +1 other reference |
| samples analysed by Dr. Tony Kampf | |
| Malcherek et al. (2010) |
| Werthessen (2016) |
| Singer et al. (2008) +1 other reference | |
| - (n.d.) +1 other reference | |
| Bandy (1938) +2 other references |
| Palache et al. (1951) |
| Dana 6 & 7. | |
| Kampf et al. (2013) |
| Kampf et al. (2013) | |
| Maskaev et al. (2007) |
| maurizio dini - analysed material | |
| Parker L.R./Salas R./Pérez G. (1963) +2 other references |
| Instituto de Investigaciones Geológicas +3 other references |
| samples analysed by Gerhard Moehn. |
| Economic Geology 86 (5) | |
| - (n.d.) +1 other reference | |
| Singer et al. (2008) |
| Samples in the I. Domeyko Museum |
| C. Ruiz Fuller/F. Peebles (1988) | |
| samples analysed by Jochen Schlüter |
| Chouinard et al. (2005) |
| "Informe preliminar sobre las minas del ... +3 other references |
| Singer et al. (2008) |
| Lavinsky (n.d.) |
| Palache et al. (1951) |
| Saric (1978) |
| SISTEMA DE INFORMACIÓN DE YACIMIENTOS ... |
| Singer et al. (2008) |
| Sulphides analysed by geology dep. of ... +1 other reference | |
| Singer et al. (2008) |
| C. Ruiz Fuller/F. Peebles (1988) |
China | |
| Jianqing Lai et al. (2004) |
| Safaa Yu collection |
| Long et al. (2025) |
| Bingbin Yang (1979) |
| Bingbin Yang (1979) | |
| National Geological Archives of China ... |
| Jianguo Yang et al. (2005) |
| Bingbin Yang (1979) |
| National Geological Archives of China ... |
| Guoqiang Tian et al. (2006) |
| Yi Li (2001) |
| Qian Wang et al. (2002) |
| Zaihong Yang (2003) |
| DING et al. (2000) |
| Zhaolong Li et al. (1981) |
| Wenliang Gao et al. (2006) |
| Zhongyou Yao et al. (1992) |
| Zongyao et al. (2005) |
| Kuanglin Yan (1978) |
| Junliang Li et al. (2009) |
| Lixia Kang et al. (2008) |
| Guangyu Zhou (1983) |
| Duan Guolian (1991) |
| Peng Wu et al. (2012) |
| Zhaolong Li and Lianying Zhang (1999) +1 other reference |
| Peters (2002) |
| Wei Liang et al. (2014) |
| Denghong Wang et al. (2009) |
| Yingxia Xu et al. (2007) |
| Han et al. (2010) |
| pubs.usgs.gov (2006) | |
| Han et al. (2007) |
| Jingchun Wang and Nan Fang (2005) |
| Mingxing Peng et al. (2006) |
| Han et al. (2014) |
| Guanghai Liu et al. (2000) +2 other references | |
| Bingbin Yang (1979) |
| Renmin Hua (1989) |
| Shen (n.d.) | |
Colombia | |
| Econ Geol (1984) |
Costa Rica | |
| Stoiber et al. (1974) |
| Ulloa et al. (2018) |
Cuba | |
| Zwahr et al. (1999) |
| Rocks & Min.: 20:169. |
Cyprus | |
| various added photos |
| D.E.Tonkacheev |
| DT personal data |
| Dmitry Tonkacheev collection | |
| Dmitry Tonkacheev |
| Ng +1 other reference | |
Czech Republic | |
| Velebil (Dě) +4 other references |
| Vtělenský J. (1959) |
| Dobešová (2012) |
| RÜSENBERG et al. (1996) |
| Velebil |
| Lapis 2002 (7/8) |
| |
| Beran (Ag, Au, Co) +2 other references |
| Sejkora et al. (2006) |
| Scharm +7 other references |
| Fengl +3 other references |
| Fojt |
| Kruťa |
| Kuttna +1 other reference |
| Fengl (2.) |
| |
Dominican Republic | |
| Colomer et al. (2013) |
DR Congo | |
| Lhoest (1992) +1 other reference |
| Kampunzu et al. (2009) |
| Wilson (2018) |
| Deleins (1975) +1 other reference |
Ecuador | |
| Singer et al. (2008) |
Egypt | |
| Gatto Rotondo et al. (2012) |
| |
| Afify et al. (2022) |
El Salvador | |
| Stoiber et al. (1974) +1 other reference |
Europe | |
| Quellmalz (1992) +1 other reference |
France | |
| Gol D. (2009) |
| Chollet Pascal Collection |
| |
| Rapport BRGM n°08354X4001 (02/1985) +1 other reference | |
| Pélisson (1989) |
| Michel Arliguie collection. |
| Coueille (1988) |
| Chollet Pascal collection - gift from ... | |
| Favreau G. et al. (1996) |
| Hohl (1994) +1 other reference |
| Wittern et al. (1997) |
| Patrice Raillard find & collection |
| Cédrick Gineste 10.09.2004 |
| Queneau (n.d.) |
| Queneau (n.d.) |
| Queneau (n.d.) |
| Forner et al. (1997) |
| Pélisson et al. (1987) |
| Berbain et al. (2019) |
| Gol (2015) |
| Queneau (n.d.) +1 other reference |
| Lheur (2023) |
| Queneau (n.d.) |
| Favreau et al. (1999) |
| Robert PECORINI (2016) |
| Pascal Chollet collection |
| J. Chervet Collection |
| Berbain +2 other references |
| Berbain et al. (2005) |
| Guitard (2010) |
| Lavinsky (n.d.) |
| Laurent J-M. (2003) |
| Pitorre (1998) |
| Heinz Fürnkranz collection (seen and visually inspected by Uwe Kolitsch) | |
| Pierrot et al. (1976) | |
| Leydet (1998) |
| R. Pierrot |
| R. Pierrot |
| van den Berg (1987) +2 other references |
Germany | |
| Walenta (1992) |
| Weiß (1990) |
| Hahn (1991) |
| Walenta (1992) |
| Walenta (1992) |
| Walenta (1992) |
| |
| Walenta (1992) | |
| Walenta (1992) | |
| Walenta (1992) |
| Mangold et al. (11/21) |
| Mangold et al. (11/21) | |
| Wittern (2001) |
| Joachim et al. (1993) |
| Weiß (1990) |
| |
| Kasiske et al. (2003) |
| Wittern (2001) |
| Hanneberg et al. (2009) +1 other reference |
| Mücke et al. (1989) |
| Rank (1985) |
| Jahn (2013) |
| Weiß (1990) |
| Collection of Steffen Michalski |
| Lapis (10) |
| Weiß (1990) |
| Jahn et al. (2003) |
| Weiß (1990) |
| Wittern et al. (1986) |
| "Lithothek" collection of the ... | |
| Weiß (1990) |
| Palache et al. (1951) +1 other reference | |
| Gröbner et al. (2011) | |
| |
| Luetcke (n.d.) |
| Schnorrer-Köhler (1988) |
| Gröbner et al. (2011) |
| Schnorrer-Köhler (1988) +1 other reference |
| Schnorrer-Köhler (1991) +1 other reference |
| Bender et al. (1994) |
| Der Aufschluss 2000 (2) |
| Gerstenberg (n.d.) | |
| Henrich (2008) |
| Schnorrer-Köhler (1987) |
| Hucko et al. (2009) |
| Graf et al. (1982) |
| Weiß (1990) |
| Schnorrer-Köhler (1988) |
| Heckmann et al. (2005) +1 other reference |
| Weiß (1990) |
| Weiß (1990) +1 other reference |
| Weiß (1990) |
| Weiß (1990) |
| Heidtke (2001) |
| Noll (1984) |
| Noll (1984) | |
| Wittern (2001) | |
| Wittern (2001) | |
| Weiß (1990) |
| Der Aufschluss Vol. 60 |
| Gröbner et al. (2011) |
| Thomas Lühr Collection |
| Wittern (2001) | |
| Hofmann (1992) |
| Schlegel (1991) |
| Kleeberg et al. (1992) |
| www.dergraul.de (2001) | |
| Wittern (2001) |
| 86. +1 other reference |
| |
| Jahn (1999) +1 other reference |
| Wittern (2001) |
| Weber (1992) |
| www.mineralienatlas.de (2016) |
| Witzke et al. (1998) |
| Witzke et al. (1998) | |
| Witzke et al. (1998) |
| Hanneberg et al. (2009) +1 other reference |
| Wittern (2001) |
| Wittern (2001) |
Greece | |
| Niedermayr (1982) |
| |
| LAPIS 24 (7/8) +1 other reference | |
| Lapis et al. (1999) |
| |
| Gröbner (2003) | |
| Rieck et al. (2018) +1 other reference |
| Lapis et al. (1999) +1 other reference |
| |
| Lapis et al. (1999) | |
| Lapis et al. (1999) | |
| Lapis 24 (1999) |
| Uwe Kolitsch (SXRD-analysed) |
| Hanke et al. (1994) | |
| Rieck (n.d.) | |
| Rieck (n.d.) |
| Lapis et al. (1999) | |
| Rieck (n.d.) | |
| Lapis et al. (1999) |
| www.brgm.fr (2003) |
| Ko Jansen |
Guatemala | |
| Econ Geol (1980) |
Hungary | |
| Szakáll: Minerals of Rudabánya |
| GEODA 2013/2 |
| Sánoor Szakáll et al. (1997) | |
| ACTA MIN. PETR. Suppl. Tomus XXXVIII. +1 other reference | |
| Szakáll et al. (1996) |
India | |
| S. G. Tenainkai et al. (1991) |
Indonesia | |
| Dana et al. (2022) |
Iran | |
| Econ Geol (1992) |
| Singer et al. (2008) |
Ireland | |
| de Haller +1 other reference |
| |
| Moreton et al. (1993) |
| Moreton et al. (1995) |
| |
| Moreton (1991) | |
Italy | |
| Piccoli et al. (2007) |
| Neschen (n.d.) | |
| Russo +1 other reference |
| Pelloux (1927) +1 other reference | |
| Annamaria Pellino et al. (Italy) | |
| Bartoli et al. (2008) |
| Bartoli et al. (2008) | |
| Scacchetti et al. (2023) | |
| Adorni F. (1997) |
| Ciuffardi et al. (2008) |
| Giuseppe Pipino - L'antica miniera di ... |
| Antofilli et al. (1983) |
| Maida (2002) |
| Orlandi et al. (1) |
| Ciriotti et al. (2008) |
| Girolami (2006) |
| Girolami (2006) | |
| Ciriotti et al. (2019) |
| Franco Luca Bonino's collection |
| De Michele (1974) |
| Roggiani (1975) +1 other reference |
| Jervis (1873) +1 other reference |
| Michele Verdi et al. (2025) +2 other references |
| Stara et al. (1993) |
| Stara et al. (1993) | |
| Stara et al. (1999) |
| Stara et al. (1996) |
| Stara et al. (1996) |
| Stara P. (1996) | |
| Stara et al. (1996) |
| Stara et al. (1996) | |
| Stara et al. (1996) | |
| De Michele (1974) | |
| Stara et al. (1996) | |
| Fernando Caboni et al. (2024) | |
| Cadoni et al. (1) +1 other reference | |
| Stara et al. (1996) |
| Stara et al. (1996) | |
| Preite et al. (2007) |
| Stara et al. (1996) |
| Antonio Gamboni collection +1 other reference | |
| Stara P. (1996) | |
| Pietracaprina et al. (1987) |
| Stara et al. (1993) |
| Stara et al. (1996) |
| |
| Garavelli et al. (1996) |
| P.Forti (1994) +1 other reference | |
| Neschen (n.d.) |
| Exel (1987) | |
| Exel (1987) |
| Exel (1987) |
| Bortolozzi (n.d.) |
| Nannoni R. |
| Biagioni et al. (2018) |
| Bazzoni et al. (2007) | |
| "Lithothek der Münchener Micromounter" ... |
| Pipino G. (1985) |
| Am Min 67:385-393 |
| C.L. Garavelli (1957) |
| N. Calanchi et al. (1976) | |
| Rögner et al. (2000) | |
| Bonifazi (2021) |
| Muenchener Micromounter-Lithothek |
| |
| Benvenuti et al. (1990) |
| Gregorio et al. (1979) |
| Betti et al. (2017) |
| Brizzi G. (1996) |
| Pegoraro S. (2014) |
| Orlandi (2013) |
Japan | |
| - (n.d.) |
| - (n.d.) |
| - (n.d.) +1 other reference |
| Uehara et al. (2014) |
| 島倉広至 et al. (2015) |
| National Science Museum |
| Brandon et al. (2009) |
| Petrov (n.d.) |
| Nagashima et al. (2016) |
Kazakhstan | |
| Bissengaliyeva +3 other references |
| Jeremolenko (2002) |
| - (2005) |
| Seltmann et al. (2005) +1 other reference |
Kosovo | |
| Féraud J. (1979) |
Laos | |
| Georgzén (2011) |
Luxembourg | |
| Philippo et al. (2007) |
| Philippo Simon (éditeur) | |
Madagascar | |
| Behier (1960) |
| Behier (1960) |
| Behier (1960) |
| Behier (1960) | |
| Behier (1960) |
| Behier (1960) |
Mexico | |
| Panczner (1987) |
| Panczner (1987) |
| Wilson et al. (1986) |
| Panczner (1987) | |
| Panczner (1987) |
| Gazquez et al. (1) |
| Panczner (1987) |
| King (1981) +1 other reference |
| Panczner (1987) |
| Peatfield (n.d.) |
| Panczner (1987) |
| Panczner (1987) |
| de la Garza +1 other reference |
| Megaw (2023) |
Morocco | |
| Tristan Mantoy's collection |
| Favreau (n.d.) |
| Favreau et al. (2006) |
| Jahn et al. (2003) |
Namibia | |
| von Bezing (2007) |
| Gebhard (1999) |
| Singer et al. (2008) |
New Zealand | |
| Moore et al. (1985) |
| Collection of Rod Martin |
| Cody et al. (1979) |
| Railton et al. (1990) |
| Collection of RJ Martin |
| Collection of RJ Martin |
| Simpson et al. (2001) |
| Courtney et al. (1990) |
| Fraser (1910) |
| Hauraki goldfield |
| Railton et al. (1990) | |
North Korea | |
| Kinosaki (1941) |
Norway | |
| Collected by Peter Andresen 2009 +1 other reference |
| Liessman (1994) |
| Oppenländer et al. (2003) |
| Garmo (2013) |
| Husdal (2019) |
| Kristiansen (1989) |
| Raade (1989) |
| Vogt (1917) +1 other reference |
| Raade (1989) |
| Atle Michaelsen collection & photo (From Torgeir Garmo) |
| Garmo (1974) +1 other reference |
| Raade (1989) |
| Ellingsen (1989) |
| N.-H. Kolderup (1929) +1 other reference |
Peru | |
| Hyršl (2010) +1 other reference |
| Singer et al. (2008) |
| Singer et al. (2008) | |
| Lewis (1964) |
| Singer et al. (2008) |
| Palache et al. (1951) |
Philippines | |
| Singer et al. (2008) |
| Singer et al. (2008) |
| Singer et al. (2008) |
Poland | |
| Łukasz Kruszewski collection |
| |
| Ł. Kruszewski PXRD data (W. Sierny specimen) |
Portugal | |
| Marques de Sá et al. (2010) |
| Silva et al. (2021) |
| |
| Alves (n.d.) |
| Pedro Alves analytical data |
| Martins da Pedra collection |
| Nunes (n.d.) |
| J. Brandao & Joao Matos: Memórias do cobre. Nota sobre a criaçao de um parque arqueo-industrial na mina da Herdade de Mostardeira (Extremos, Portugal) |
| Nunes (n.d.) |
| In the collection of Pierre Rosseel |
| Milá et al. (2014) | |
| Alves (2017) |
Romania | |
| Onac (2002) | |
| www.minerals-of-the carpathians.eu (2009) |
| Onac (2002) +1 other reference |
| www.minerals-of-the-carpathians |
| Arliguie M | |
| Szakáll (2002) | |
| Acta Mineralogica Petrographica |
| Onac (2009) |
| B. Onac et al (2009, July) | |
| Huber et al. (1996) |
| 1-Rădulescu Dan |
| Ł. Kruszewski visual identification +1 other reference |
| Udubasa et al. (1996) +1 other reference |
| Ł. Kruszewski visual identification |
Russia | |
| Vakh et al. (2009, March) +1 other reference |
| Cesnokov et al. (1998) |
| Savva et al. (2012) |
| Pekov (1998) |
| Pekov et al. (2013) |
| Bortnikova et al. (2017) |
| Pavel.M. Kartashov (n.d.) |
| Belogub et al. (2008) |
| Shcherbakova (2004) | |
| Grant et al. (2001) |
| Pavel M. Kartashov analytical data (2012) |
| Yarosh et al. (1955) |
| D. Krinov data |
| Kasatkin et al. (2021) |
| Gongalsky et al. (2019) |
| Kasatkin et al. (2014) |
| Eremin et al. (2014) |
Saudi Arabia | |
| Bakhsh (2018) |
| Bakhsh (2018) | |
Serbia | |
| Albrecht von Quadt et al. (2007) |
Slovakia | |
| Pauliš |
| Pauliš +4 other references |
| Koděra (1986) |
| |
| Koděra (1986) |
| Koděra (1986) | |
| Miškovic J. (1990) | |
| Grecula (1995) |
| Koděra (1986) |
| Grecula (1995) |
| Kodě +1 other reference |
| Martin Števko-unpublished | |
| Ďuďa (1993) |
| Pauliš et al. (2002) |
| Pauliš et al. (2002) | |
| Koděra (1986) | |
| Koděra (1986) |
| Števko M. (2022) |
| Koděra (1986) | |
| Pauliš et al. (2002) |
| Sottnik et al. (1998) |
| Koděra (1986) |
| Duda |
| Duda et. all. |
Slovenia | |
| Scopolia - Journal of the Slovenian ... |
South Africa | |
| Cairncross et al. (2008) |
| Cairncross et al. (1995) |
| Malcolm Southwood (2002) | |
| Paul Meulenbeld photo ID 1179785 |
| Cairncross et al. (1995) |
| Cairncross et al. (1995) |
| Meulenbeld et al. (2014) |
| Atanasova et al. (2016) |
| Schoch et al. (1985) |
| Cairncross (2004) | |
| Cairncross (2004) |
Spain | |
| P Rhodes collection |
| Rewitzer et al. (2023) |
| Navarro et al. (2008) |
| Navarro et al. (2008) | |
| A. Arribas et al. (2005) |
| Favreau (n.d.) |
| Sainz de Baranda Graf et al. (2023) | |
| Sainz de Baranda Graf et al. (2023) | |
| G. Leal et al. (2005) | |
| Colección Juan A.M. Barnestein. | |
| Rewitzer et al. (2020) |
| Valente et al. (2013) |
| Valente et al. (2013) | |
| Valente et al. (2013) | |
| Valente et al. (2013) | |
| Calvo et al. (1999) |
| Calvo Rebollar (2014) |
| Romero Silva et al. (2013) |
| |
| Bareche (2005) |
| Mineralogistes de Catalunya (2/3) |
| Mineralogistes de Catalunya (1997) |
| Joan Rosell 2023 |
| Joan Rosell |
| Pedro Mingueza et al. (2022) |
| Calvo Rebollar (2014) |
| Jiménez R. et al. (2004) |
| Jordá (2008) |
| Jimenez R. et al. (2004) | |
| Calvo Rebollar (2014) |
| Casanova Honrubia |
| Casanova Honrubia |
Sweden | |
| |
| Öhman et al. (2000) |
| Persson (2000) |
Switzerland | |
| Philipp R. (1983) |
| Stalder et al. (1998) |
| Gröbner J. (2018) |
| Stalder et al. (1998) |
| Perroud et al. (1987) +2 other references |
| Ansermet (2012) |
| Ansermet (2012) |
| Stalder et al. (1998) +1 other reference |
Turkey | |
| Kautz et al. (1966) |
| Demir et al. (2008) |
UK | |
| Hogg (1825) +1 other reference |
| Dana 7:II:490 +1 other reference |
| Royal Cornwall Polytechnic Society (1870) +1 other reference |
| Paul De Bondt collection. |
| Phillips (1823) |
| Phillips (1823) | |
| Golley et al. (1995) |
| Golley et al. (1995) |
| Smyth (1882) |
| T.B. Wilson Collection |
| Ansermet (2007) |
| Hall (1868) |
| Hall (1868) +2 other references |
| Collins (1871) |
| Richard de Nul collection | |
| Golley et al. (1995) | |
| Golley et al. (1995) |
| A.Rowan Collection |
| Norman Wilson collection |
| Kingsbury (xxxx) +1 other reference |
| |
| |
| Ford et al. (1993) |
| Ford et al. (1993) |
| Paul De Bondt collection. |
| Ford et al. (1993) |
| Livingstone |
| |
USA | |
| Cook et al. (1982) |
| Cook et al. (1982) | |
| Dean (1995) |
| Cook et al. (1982) |
| USGS OFR 2004-1200 (Hawley,2004) |
| - (2008) |
| - (2008) |
| - (2008) |
| - (2008) | |
| - (2008) | |
| - (2008) |
| USGS OFR 2003-404 (Hudson,2003) +1 other reference | |
| - (2008) | |
| - (2008) | |
| - (2008) | |
| - (2008) | |
| Galbraith et al. (1959) +1 other reference |
| Mitchell (1921) +1 other reference |
| Anthony et al. (1995) | |
| Merwin et al. (1937) +1 other reference |
| Luetcke (n.d.) |
| Luetcke (n.d.) |
| MRDS database Dep. ID file #10037134 |
| Leicht (1971) +1 other reference |
| Granger (1962) |
| MRDS database Dep. ID #10026861 +1 other reference |
| - (2005) | |
| - (1951, July) +2 other references |
| Eastlick |
| Galbraith (1959) +1 other reference |
| Peterson et al. (1951) +2 other references |
| Olmstead et al. (1966) +1 other reference |
| Anthony et al. (1995) |
| Granger (1969) +1 other reference |
| Granger (1969) +1 other reference |
| Granger (1959) |
| MRDS database Dep. ID #10039447 +1 other reference |
| Besse (1981) |
| - (2005) |
| MRDS database Dep. ID #10026888 |
| MRDS database Dep. ID #10048292 |
| Dana 6: 945 | |
| Lindgren (1905) +4 other references | |
| Lindgren (1905) +4 other references | |
| MRDS database Dep. ID #10088902 |
| MRDS database Dep. ID #10282444 +1 other reference | |
| Collection Elmar Lackner |
| Anthony et al. (1995) |
| Thomas (1949) +2 other references |
| Granger et al. (1962) +1 other reference |
| MRDS file #10186198. |
| Witkind (1963) +1 other reference |
| Schrader (1915) +2 other references |
| Creasey (1955) |
| collected by and in the collection of ... |
| Schrader (1915) | |
| Galbraith (1959) | |
| Anthony et al. (1995) |
| Galbraith (1959) +1 other reference |
| MRDS database Dep. ID file #10039683 | |
| Singer et al. (2005) |
| Galbraith (1959) +2 other references |
| Simons (1964) +1 other reference | |
| Galbraith (1959) | |
| Simons (1964) +1 other reference | |
| Anthony et al. (1995) |
| C.R. Williams (1970) |
| Anthony et al. (1995) | |
| Barnes et al. (1983) |
| Wilson (1934) +3 other references |
| MRDS database Dep. ID file #10103747 | |
| Schrader (1915) |
| Schrader (1915) | |
| Schrader (1915) |
| Schrader & Hill (1915) |
| Schrader (1917) +1 other reference |
| - (1915) |
| Dana 6: 1094 +5 other references |
| Anthony et al. (1995) |
| Brian Beck Collected |
| Anthony et al. (1995) |
| Galbraith (1959) |
| Anderson et al. (1955) |
| Anthony et al. (1995) | |
| Singer et al. (2008) | |
| Galbraith (1959) | |
| Anderson et al. (1955) | |
| Anderson et al. (1955) |
| MRDS database Dep. ID #10026927 | |
| Anderson et al. (1955) | |
| Anderson et al. (1955) |
| Guild (1917) +1 other reference |
| Anthony et al. (1995) |
| Anthony et al. (1995) |
| Howard (1987) +1 other reference |
| Schaller (1903a) +4 other references |
| - (2005) | |
| Rocks & Minerals: 16: 411. +5 other references |
| Clark et al. (1963) +3 other references |
| Silliman et al. (1867a) +1 other reference |
| Dunning et al. (2002) |
| Jay Buscio +1 other reference |
| Goldstone (1890) +4 other references |
| Walstrom (n.d.) |
| - (2005) |
| www.mineralsocal.org (1999) |
| Hall (1963) +3 other references |
| Mackevett (1953) +4 other references |
| Adams (2010) |
| California Division of Mines and ... |
| Sharp (1959) +2 other references |
| Bradley (1938) +1 other reference |
| Kampf et al. (2018) |
| Marty | |
| Mining and Scientific Press (1861) +2 other references |
| Silliman et al. (1867a) +2 other references |
| Dunning et al. (2005) |
| Dunning et al. (2005) | |
| Dunning et al. (2005) | |
| - (2005) |
| Hewett (1956) +2 other references |
| |
| Southern Pacific Company (1964b) +2 other references |
| Hewett (1956) +2 other references |
| "The Blue Bell Claims San Bernardaino ... |
| Collected by and in the collection of ... +2 other references | |
| Hanks (1884) +1 other reference |
| Nordstrom et al. (1999) |
| McCulloch et al. (1964) +2 other references |
| Dana 7: II: 490 & 626. +4 other references |
| - (1908, September) +1 other reference |
| Eckel et al. (1997) |
| U.S. Geological Survey Professional ... +2 other references |
| - (2005) |
| Eckel et al. (1997) |
| Hanson et al. (Rusty) | |
| Eckel et al. (1997) |
| Moench et al. (1966) |
| Moench et al. (1966) | |
| Harrison et al. (1959) |
| Moench et al. (1966) |
| Moench et al. (1966) | |
| Eckel et al. (1997) | |
| Eckel et al. (1997) |
| Eckel et al. (1997) |
| - (2005) |
| - (2005) |
| Eckel et al. (1997) |
| Eckel et al. (1997) | |
| Eckel et al. (1997) | |
| W. Cummings | |
| - (2005) |
| Eckel et al. (1997) |
| Eckel et al. (1997) |
| Shannon et al. (1985) | |
| Eckel et al. (1997) |
| Eckel et al. (1997) |
| - (2005) |
| Kucera (2021) | |
| - (2005) | |
| Eckel et al. (1997) |
| Alexander Wong Collection |
| Eckel et al. (1997) |
| Eckel et al. (1997) |
| - (2005) |
| Gray (1993) |
| Eckel et al. (1997) | |
| Eckel et al. (1997) |
| Eckel et al. (1997) |
| Eckel et al. (1997) | |
| In the collection of Alex Earl |
| Lovering et al. (1950) |
| Lovering et al. (1950) |
| Eckel et al. (1997) |
| USGS PP 223 (Lovering,1950) | |
| Carnein et al. (2005) |
| Carnein et al. (2005) | |
| Carnein et al. (2005) | |
| Carnein et al. (2005) | |
| Carnein et al. (2005) | |
| Eckel et al. (1997) | |
| Jeremy Zolan Collecton- Specimens ... |
| Januzzi et al. (1976) |
| Ream (1995) |
| - (2005) |
| Ream (1995) |
| Ream (2004) | |
| Rocks & Min.: 21:144-145 +1 other reference |
| Ostrander et al. (1940) |
| Ostrander et al. (1940) |
| Mines of the Washington D.C Area | |
| Rocks & Min.: 22:1023. |
| Rocks & Min.: 21:665. |
| Anderson (1982) |
| Heinrich et al. (2004) |
| Sherwood et al. (1998) |
| Sherwood et al. (1998) |
| Sherwood et al. (1998) |
| Sherwood et al. (1998) | |
| Sherwood et al. (1998) |
| C. DeGrave (pers.comm.) |
| Conroy (2023) | |
| Sherwood et al. (1998) |
| Sherwood et al. (1998) | |
| Leonhard (1886) |
| Dana 6:1084. |
| Jensen et al. (2012) |
| - (2005) |
| Winchell (1914) +2 other references |
| Weed (1912) |
| Anaconda Mining Company Collection | |
| Guilbert and Zeihen 1964 +1 other reference | |
| Weed (1912) | |
| Rocks & Min.: 16: 243. +2 other references | |
| Weed (1912) |
| - (2005) |
| Schilling (1979) +2 other references |
| - (2005) |
| - (2005) | |
| Jensen et al. (1995) |
| Castor et al. (2004) | |
| - (2005) |
| Castor et al. (2004) | |
| Castor et al. (2004) |
| Castor et al. (2004) | |
| Reid et al. (2010) |
| Mineral News (1990) |
| Ranta (1967) |
| Castor et al. (2004) | |
| USGS Bull 997 |
| Castor et al. (2004) |
| Dana 7:II:490. |
| - (1911) |
| Castor et al. (2004) |
| Castor et al. (2004) |
| Ross (1961) |
| Kleinhampl et al. (1984) |
| Rocks & Minerals (2010) |
| Cooper et al. (1991) |
| Ameican Mineralogist +1 other reference |
| Jensen (1993) | |
| - (2005) |
| - (2005) |
| Vikre (1981) | |
| Bruce Kelley Collection |
| Castor et al. (2004) |
| Castor et al. (2004) |
| NBMG Bull 70 Geology and Mineral ... +1 other reference |
| NBMG Bull 70 Geology and Mineral ... +1 other reference |
| Castor et al. (2004) |
| Castor et al. (2004) | |
| NBMG Bull 70 Geology and Mineral ... | |
| NBMG Bull 70 Geology and Mineral ... | |
| Castor et al. (2004) |
| Castor et al. (2004) | |
| - (1976) |
| - (1976) |
| Maertens (2007) |
| McLemore et al. (1996) |
| - (2005) +1 other reference |
| Northrop et al. (1996) | |
| Lasky et al. (1930) |
| Northrop et al. (1996) | |
| Northrop et al. (1996) | |
| ... | |
| M Massis collection | |
| Northrop et al. (1996) | |
| 2008 New Mexico Mineral Symposium ... |
| Northrop et al. (1996) | |
| Northrop et al. (1996) | |
| Walstrom (n.d.) |
| Northrop et al. (1996) |
| NMBMMR OFR 166 |
| Northrop et al. (1996) | |
| Charles Creekmur collection |
| All minerals were personally collected |
| Northrop et al. (1996) |
| D. Wells collection |
| Northrop et al. (1996) |
| Northrop et al. (1996) | |
| R&M 67:6 p390-395 | |
| Northrop et al. (1996) | |
| Northrop et al. (1996) |
| Harley (1934) |
| Northrop et al. (1996) | |
| Harley (1934) | |
| Patrick E. Haynes |
| Northrop et al. (1996) |
| Northrop et al. (1996) |
| Gibbs (1989) | |
| Northrop et al. (1996) | |
| GF Loughlin (1942) +1 other reference | |
| Patrick Haynes collection +1 other reference | |
| Rocks & Minerals: 60: 83. +1 other reference |
| Genth et al. (1881) |
| Rocks & Min.: 23:113. |
| Smith et al. (1997) |
| Lobell (1986) | |
| - (2005) | |
| R&M 72:4 pp 252-264 |
| Lisa19 | |
| - (1952) |
| Rocks & Minerals 81:229-234 |
| Sloto (1989) |
| Matrix +1 other reference |
| Dana 6:1069 +2 other references |
| Lapham et al. (1965) |
| Dana 6: 1069. |
| Rocks & Minerals 54:4 pp173-175 +1 other reference |
| Roberts et al. (1965) |
| Roberts et al. (1965) | |
| Roberts et al. (1965) | |
| Roberts et al. (1965) |
| Roberts et al. (1965) |
| Roberts et al. (1965) | |
| Dana 6:945. |
| Dana 6:82 |
| www.gamineral.org. +2 other references | |
| Smith (1991) |
| Self-collected by David Aldridge |
| Rocks & Min. | |
| Butler (1913) |
| Butler (1913) +1 other reference |
| - (2005) |
| - (2005) |
| Bullock (1981) |
| Rosenzweig et al. (1955) +1 other reference | |
| - (2005) |
| Page et al. (1956) +2 other references | |
| Bullock (1981) |
| - (2005) |
| Thorne (n.d.) |
| James R. Wilson (1995) +1 other reference |
| Bullock (1981) | |
| Bullock (1981) | |
| Bullock (1981) +1 other reference | |
| Bullock (1981) +1 other reference | |
| Bullock (1981) | |
| Thorne (n.d.) |
| Bullock (1981) | |
| Bullock (1981) | |
| Bullock (1981) |
| Thorne (n.d.) +2 other references |
| Patrick Haynes. IDs by the late Howard ... | |
| Kampf et al. (2018) | |
| Bullock (1981) | |
| Min News 5:10 p1-5 | |
| USGS Bull 1125 +1 other reference |
| Thorne (n.d.) | |
| USGS TEI #514 +2 other references | |
| - (2005) | |
| Trites et al. (1958) +2 other references | |
| Bullock (1981) |
| Bullock (1981) |
| Bullock (1981) +1 other reference |
| - (2005) | |
| Thorne (n.d.) | |
| Bullock (1981) | |
| Rick Dalrymple Collection | |
| Bullock (1981) | |
| Bullock (1981) | |
| Bullock (1981) +1 other reference |
| Bullock (1981) |
| Bullock (1981) | |
| Rocks & Minerals 83:1 pp 52-62 |
| Bullock (1981) |
| Bullock (1981) | |
| Bullock (1981) |
| Bullock (1981) |
| Bullock (1981) |
| - (2005) |
| Dietrich (1990) |
| Dietrich (1990) |
| Dietrich (1990) |
| Dietrich (1990) | |
| Dietrich (1990) |
| Dietrich (1990) |
| Dietrich (1990) |
| Dietrich (1990) |
| Dietrich (1990) |
| Kilburn et al. (1996) |
| Valentine et al. (1960) +1 other reference |
| Valentine et al. (1960) | |
| Cannon (1975) |
| Valentine et al. (1960) |
| Jones +1 other reference |
| - (2005) |
| Hausel et al. (2001) | |
| Wyoming State Geological Survey +2 other references | |
Zimbabwe | |
| Frei (2005) |
Quick NavTopAbout ChalcanthiteUnique IdentifiersIMA Classification Classification Mineral SymbolsPronunciation Physical Properties Optical Data Chemistry Crystallography Crystal StructureX-Ray Powder DiffractionGeological EnvironmentType Occurrence SynonymsOther LanguagesVarietiesRelationshipsCommon AssociatesStrunz-MindatOther InformationInternet Links References Localities Locality List
Planet Mine, Planet Mine group, Planet, Santa Maria Mining District, Buckskin Mountains, La Paz County, Arizona, USA
