Catapleiite
A valid IMA mineral species - grandfathered
This page is currently not sponsored. Click here to sponsor this page.
About Catapleiite
Formula:
Na2Zr(Si3O9) · 2H2O
Colour:
Dark brown, reddish brown, flesh red, yellowish red, colourless, light grey, beige to tan, light yellow, orange, light blue
Lustre:
Vitreous, Dull
Hardness:
5½ - 6
Specific Gravity:
2.65 - 2.9
Crystal System:
Monoclinic
Member of:
Name:
First described in 1850 from Låven, Langesundsfjorden, Norway by the Norwegian mineralogist Paul Christian Weibye (1819-1865). It was found by him the year before, in 1849. The name is from the Greek κατα = 'with' and πλειον = 'more' and refers to its association with many other rare minerals.
Type Locality:
Dimorph of:
The monoclinic dimorph of gaidonnayite. The sodium analogue of calcium-catapleiite.
Visit gemdat.org for gemological information about Catapleiite.
Visit gemdat.org for gemological information about Catapleiite.Unique Identifiers
Mindat ID:
919
Long-form identifier:
mindat:1:1:919:5
IMA Classification of Catapleiite
Approved, 'Grandfathered' (first described prior to 1959)
First published:
1850
Classification of Catapleiite
9.CA.15
9 : SILICATES (Germanates)
C : Cyclosilicates
A : [Si3O9]6- 3-membered single rings (dreier-Einfachringe), without insular complex anions
9 : SILICATES (Germanates)
C : Cyclosilicates
A : [Si3O9]6- 3-membered single rings (dreier-Einfachringe), without insular complex anions
59.2.2.1
59 : CYCLOSILICATES Three-Membered Rings
2 : Three-Membered Rings, hydrated
59 : CYCLOSILICATES Three-Membered Rings
2 : Three-Membered Rings, hydrated
14.10.24
14 : Silicates not Containing Aluminum
10 : Silicates of Zr or Hf
14 : Silicates not Containing Aluminum
10 : Silicates of Zr or Hf
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference |
|---|---|---|
| Ctp | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Physical Properties of Catapleiite
Vitreous, Dull
Transparency:
Transparent, Translucent
Colour:
Dark brown, reddish brown, flesh red, yellowish red, colourless, light grey, beige to tan, light yellow, orange, light blue
Streak:
White to pale yellow
Hardness:
5½ - 6 on Mohs scale
Tenacity:
Brittle
Cleavage:
Perfect
Perfect on {100}
Imperfect on {101} {102}
Perfect on {100}
Imperfect on {101} {102}
Fracture:
Irregular/Uneven
Density:
2.65 - 2.9 g/cm3 (Measured) 2.77 g/cm3 (Calculated)
Optical Data of Catapleiite
Type:
Biaxial (+)
RI values:
nα = 1.591 nβ = 1.592 nγ = 1.627
2V:
Measured: 40°
Max. Birefringence:
δ = 0.036
Based on recorded range of RI values above.
Based on recorded range of RI values above.
Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
Surface Relief:
Moderate
Dispersion:
r < v moderate
Chemistry of Catapleiite
Mindat Formula:
Na2Zr(Si3O9) · 2H2O
Element Weights:
Common Impurities:
Ca,Fe
Chemical Analysis
Oxide wt%:
| 1 | |
|---|---|
| SiO2 | 44.5 % |
| ZrO2 | 32.7 % |
| CaO | 0.4 % |
| Na2O | 13.4 % |
| H2O (calc.) | 9.0 % |
| Total: | 100 % |
Sample references:
| ID | Locality | Reference | Notes |
|---|---|---|---|
| 1 | Bratthagen 1, Lågendalen, Hedrum, Larvik Commune, Vestfold, Norway | Pale brownish plates 2cm across embedded in feldspar. |
Crystallography of Catapleiite
Crystal System:
Monoclinic
Cell Parameters:
a = 12.799 Å, b = 7.419 Å, c = 20.157 Å
β = 90.41°
β = 90.41°
Ratio:
a:b:c = 1.725 : 1 : 2.717
Unit Cell V:
1,913.97 ų (Calculated from Unit Cell)
Z:
8
Morphology:
Pseudohexagonal, rosettes.
Twinning:
Polysynthetic at 30, 60, 90 degrees.
Comment:
monoclinic, pseudohexagonal I2/c
Crystallographic forms of Catapleiite
Crystal Atlas:
Image Loading
Click on an icon to view
Catapleiite no.6 - Goldschmidt (1913-1926)
Catapleiite no.28 - Goldschmidt (1913-1926)
Catapleiite no.29 - Goldschmidt (1913-1926)
Catapleiite no.30 - Goldschmidt (1913-1926)
Catapleiite no.31 - Goldschmidt (1913-1926)
3d models and HTML5 code kindly provided by
www.smorf.nl.
Toggle
Edge Lines | Miller Indices | Axes
Transparency
Opaque | Translucent | Transparent
View
Along a-axis | Along b-axis | Along c-axis | Start rotation | Stop rotation
Toggle
Edge Lines | Miller Indices | Axes
Transparency
Opaque | Translucent | Transparent
View
Along a-axis | Along b-axis | Along c-axis | Start rotation | Stop rotation
Crystal Structure
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File Best | x | y | z | a | b | c
CIF File Best | x | y | z | a | b | c
Rotation
Stop | Start
Stop | Start
Labels
Console Off | On | Grey | Yellow
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0012471 | Catapleiite | Ilyushin G D, Voronkov A A, Ilyukhin V V, Nevskii N N, Belov N V (1981) Crystal structure of natural monoclinic catapleiite, Na2ZrSi3O9*2H2O Doklady Akademii Nauk SSSR 260 623-627 | 1981 | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder Diffraction
Loading XRD data...
Data courtesy of RRUFF project at University of Arizona, used with permission.
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 3.94 Å | (100) |
| 3.05 Å | (100) |
| 2.96 Å | (100) |
| 2.69 Å | (100) |
| 6.35 Å | (90) |
| 1.969 Å | (60) |
| 5.37 Å | (50) |
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| Stage 4b: Highly evolved igneous rocks | >3.0 |
| 35 : Ultra-alkali and agpaitic igneous rocks |
Geological Setting:
Syenites and nepheline syenites
Type Occurrence of Catapleiite
Place of Conservation of Type Material:
Swedish Museum of Natural History, Stockholm, Sweden, number 334509.
Geological Setting of Type Material:
Nepheline syenite pegmatite.
Associated Minerals at Type Locality:
Synonyms of Catapleiite
Other Language Names for Catapleiite
Dutch:Catapleiiet
Russian:Катаплеит
Simplified Chinese:单斜钠锆石
Spanish:Catapleiita
Catapleita
Catapleita
Traditional Chinese:單斜鈉鋯石
Relationship of Catapleiite to other Species
Member of:
Other Members of Catapleiite Group:
| Calciocatapleiite | CaZr(Si3O9) · 2H2O | Orth. mmm (2/m 2/m 2/m) |
Structurally related to group(s):
Forms a series with:
Common Associates
Associated Minerals Based on Photo Data:
| 237 photos of Catapleiite associated with Aegirine | NaFe3+Si2O6 |
| 96 photos of Catapleiite associated with Microcline | K(AlSi3O8) |
| 73 photos of Catapleiite associated with Natrolite | Na2Al2Si3O10 · 2H2O |
| 59 photos of Catapleiite associated with Albite | Na(AlSi3O8) |
| 52 photos of Catapleiite associated with Analcime | Na(AlSi2O6) · H2O |
| 47 photos of Catapleiite associated with Fluorite | CaF2 |
| 40 photos of Catapleiite associated with Calcite | CaCO3 |
| 35 photos of Catapleiite associated with Petarasite | Na5Zr2(Si6O18)(Cl,OH) · 2H2O |
| 33 photos of Catapleiite associated with Manganoneptunite | KNa2Li(Mn2+)2Ti2[Si4O12]2 |
| 30 photos of Catapleiite associated with Serandite | NaMn2+2Si3O8(OH) |
Related Minerals - Strunz-mindat Grouping
| 9.CA. | UM1975-18-SiO:Mn | α-MnSiO3 |
| 9.CA.05 | Bazirite | BaZr(Si3O9) |
| 9.CA.05 | Benitoite | BaTi(Si3O9) |
| 9.CA.05 | Pabstite | Ba(Sn,Ti)(Si3O9) |
| 9.CA.10 | Wadeite | K2Zr(Si3O9) |
| 9.CA.15 | Calciocatapleiite | CaZr(Si3O9) · 2H2O |
| 9.CA.20 | Pseudowollastonite | CaSiO3 |
| 9.CA.25 | Margarosanite | Ca2PbSi3O9 |
| 9.CA.25 | Walstromite | BaCa2(Si3O9) |
| 9.CA.25 | Anatolygurbanovite | SrCa2Si3O9 |
| 9.CA.25 | Breyite | Ca3Si3O9 |
| 9.CA.30 | Bobtraillite | (Na,◻)12(◻,Na)12Sr12Zr14(Si3O9)10[Si2BO7(OH)2]6 · 12H2O |
| 9.CA.35 | Rogermitchellite | Na6Sr12Ba2Zr13Si39B4O123(OH)6 · 20H2O |
Other Information
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Catapleiite in petrology
An essential component of rock names highlighted in red, an accessory component in rock names highlighted in green.
Internet Links for Catapleiite
mindat.org URL:
https://www.mindat.org/min-919.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
References for Catapleiite
Reference List:
Weibye, P. H., Berlin, N. J., Sjögren, K. A., von Borck, J. B. (1850) Neue Mineralien aus Norwegen beschrieben von P.H. Weibye; analysirt von N.J. Berlin, K.A. Sjögren und J.B. von Borck (Erster Theil) [1.Tritomit, 2. Katapleiit, 3.Atheriasit, 4. Eudnophit.]. [New minerals from Norway described by P.H. Weibye; analyzed by N.J. Berlin, K.A. Sjögren and J.B. von Borck (first part) [1.tritomite, 2. catapleiite, 3. atheriasite, 4. eudnophite.].]. Annalen der Physik und Chemie, 155. 299-304 doi:10.1002/andp.18501550210
Flink, Gust. (1893) Om några mineral från Grönland. Geologiska Föreningen i Stockholm Förhandlingar, 15 (4) 195-208 doi:10.1080/11035899309442185
Foshag, William F. (1923) Catapleiite from Magnet Cove, Arkansas. American Mineralogist, 8 (4). 70-72
Pendlebury, G. B. (1964) Catapleiite from St. Hilaire mountain, Quebec. The Canadian Mineralogist, 8 (1) 120-121
Localities for Catapleiite
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
Quick NavTopAbout CatapleiiteUnique IdentifiersIMA Classification Classification Mineral SymbolsPhysical Properties Optical Data Chemistry Chemical AnalysisCrystallography Crystallographic forms Crystal StructureX-Ray Powder DiffractionGeological EnvironmentType Occurrence SynonymsOther LanguagesRelationshipsCommon AssociatesStrunz-MindatOther InformationCatapleiite in petrologyInternet Links References Localities Locality List
Poudrette quarry, Mont Saint-Hilaire, La Vallée-du-Richelieu RCM, Montérégie, Québec, Canada
