  Database Scaling Strategies MASTERCLASS
• 2.
  Exploring Scaling Approaches Guilherme Nogueira(Gui) MASTERCLASS
• 3.
  Ask the best5 questions in chat and win a copy of Database Performance at Scale
• 4.
  Database Scaling StrategiesMasterclass Vertical vs. Horizontal
• 5.
  Database Scaling StrategiesMasterclass Horizontal Scaling Pros: ■ Leveraging commodity hardware ■ The sky's the limit (infinite headroom) Cons: ■ Distributed Systems Tax ● Network overhead ● Challenging long tail latency ● Consistency challenges ● "N+1" failure modes ■ Different hardware involved = higher failure chance 5 …
• 6.
  Database Scaling StrategiesMasterclass Vertical Scaling Pros: ■ No arch changes ■ Low operational complexity ■ Lower noisy neighbour risk Cons: ■ Hard ceiling in compute ■ Exponential cost curve ■ Diminishing returns in going HUGE ■ Only if your DB is not prepared for it 😉 6
• 7.
  Database Scaling StrategiesMasterclass Both worlds combined Is there a right way to do this? Leverage the best of both worlds 😉 Anonymized Use-case: North America EV Manufacturer ■ AWS to On-premises ■ 256 vCPUs / 2TB ram ■ 180TB storage (NVMes) ■ 30 nodes (and growing FAST) ■ ~4PB dataset (post-replication, compression) 7 …
• 8.
  Database Scaling StrategiesMasterclass Sharding and Distribution
• 9.
  Database Scaling StrategiesMasterclass Implicit vs Explicit sharding Explicit: App-level or plugin-driven ■ Plugins might jeopardize long-term plans ■ Cumbersome to maintain ■ Error-prone ■ Hard to react Implicit: DB-native ■ Built-in to the tech ● Core DB, coordinators, drivers, etc ■ Perfected over time with the DB ■ Offloaded to the DB maker 9 Explicit Examples Commonly uses explicit app-level or plugin sharding. Implicit Examples Native implementations like ScyllaDB, Cassandra, and MongoDB.
• 10.
  Database Scaling StrategiesMasterclass Sharding types Per-node sharding ■ Split at a node level ■ Sometimes virtualized ● Multiple virtual nodes on a single physical one ■ Rebalance involves a node's volume of data Per-core sharding ■ Highly specialized ■ Each vCPU owns a piece of the dataset ■ Maximizes performance ■ Each vCPU is equally busy ■ Minimizes contention 10
• 11.
  Database Scaling StrategiesMasterclass Rebalance time A.K.A. what happens when you add a node? ■ Cost of data movement (streaming) ● CPU maxed-out ● Disks busy ● Network spikes ● Tablets solves this! ■ DB behavior during resource shortage ● Cassandra has to throttle streaming/compaction in config ● ScyllaDB has Workload Prioritization ■ Client-side things to watch out for ● Application latency ● Streaming resource overhead 11
• 12.
  Database Scaling StrategiesMasterclass Rebalancing mishaps Scaling is finished! Why are the dashboards red? What to monitor for? ■ Clients connection health ■ Hot nodes/shards ■ Data imbalance ■ Post-scaling operations ● Compactions (Cassandra) ● Aerospike (Migrations) ● MongoDB (Compactions) 12
• 13.
  Database Scaling StrategiesMasterclass Scaling Tradeoffs
• 14.
  Database Scaling StrategiesMasterclass Complexity beyond simply adding nodes ■ Cost ● Scale too soon = wastes $ on idling resources ● Scale too late = risks SLAs, lose $ ■ Complexity ● Operational overhead ■ Latency ● Busy systems ● Higher latency ■ Decision Making ● When to trigger scaling? ● Cost / Risk tradeoffs 14
• 15.
  Database Scaling StrategiesMasterclass Why Scaling in NoSQL is different ■ Built-in to the technology ● Lower application overhead ■ Aimed at scale ● Massive datasets ● High throughput ● Lower latency ■ Frequent scaling ● Day/Night cycles ● Business/Weekend days 15
• 16.
  Database Scaling StrategiesMasterclass Scaling Incoherency Doubling cluster size != Doubling DB capacity ■ Neo4j ● Graphs computing is mathematically hard to scale ■ MongoDB ● Especially for write capacity ● Add'l mongos and config servers ■ Cassandra ● Although improved on latest versions ■ DynamoDB ● Not a cluster per-se ● Scaling takes minutes to react, effectuate ■ HBase ● Heavy cluster-wide rebalance tasks, often hurts performance 16
• 17.
  Database Scaling StrategiesMasterclass Auto and Elastic Scaling
• 18.
  Database Scaling StrategiesMasterclass Auto vs. Elastic Scaling Auto-scaling ■ Reactive to metrics ● CPU, RAM, Disk I/O, Request latency ■ DBs are not stateless ■ Data has a weight ● Shifting it around costs CPU, Disk and Network I/O ● Even when restoring from a backup Elastic scaling ■ Leverages Cloud Infrastructure ■ Scales in incremental steps ■ Instances of different types ● Works under circumstances where others would fail 18
• 19.
  Database Scaling StrategiesMasterclass ■ To provision or not to provision? ● Over-provisioning vs under-provisioning ■ Consequences of an overloaded system? ● Elevated latency ● Drop in throughput ● Client-side DB timeouts ● App calls timeout ● … ● Users see the effect Cost of Elasticity 19
• 20.
  Database Scaling StrategiesMasterclass Tactical Responses
• 21.
  Database Scaling StrategiesMasterclass External caches are not a solution ■ Caches always improve performance ● Right!? ■ Often: ● Application Complexity ● Additional Latency ● Additional Cost ● Lowers Service Availability ● Ruins DB's cache ● Wastes leverage DB's potential ● Reduces Security Check out: https://www.scylladb.com/2024/05/29/eliminating-external-database-caches/ 21
• 22.
  Database Scaling StrategiesMasterclass Configuration Tuning Tune the problem away? ■ Cassandra has tons of throttling configurations ● Streaming ● Compaction ● Helps during the event, but requires babysitting ■ ScyllaDB allows tuning it too, but… ● You don't usually need them ● Workload Prioritization applies to internal groups as well ■ Streaming is one of them 😉 ● Tablet-based streaming is much more efficient ■ Requires zero tuning 22
• 23.
  Database Scaling StrategiesMasterclass Client-side tactics Best practices for steady-state AND scaling time ■ Up-to-date drivers ■ Load-balancing client drivers ● If ScyllaDB: Shard + Tablet-aware ■ Retry policies + speculative retries ■ Use DNS endpoints ● Improve discoverability ● Curtails client-side changes after replaced 23
• 24.
  Pass the exam andwin a certificate and swag pack!
• 25.
  Submit an acceptedreview of ScyllaDB on G2 and win a $50 gift card!* *While supplies last. Earn $50!
• 26.
  Database Scaling StrategiesMasterclass Guilherme Nogueira (Gui) Technical Director ScyllaDB guilherme.nogueira@scylladb.com Keep in touch!
