Ferrihydrite
A valid IMA mineral species
This page is currently not sponsored. Click here to sponsor this page.
About Ferrihydrite
Formula:
Fe3+10O14(OH)2
Previously given as Fe3+5O3(OH)9.
Colour:
Dark brown, yellow-brown
Specific Gravity:
3.96
Crystal System:
Trigonal
Member of:
Name:
For the chemical composition (hydrated ferric iron oxide).
Co-Type Localities:
Isostructural with:
The Fe analogue of akdalaite.
A poorly crystalline nanomineral built up of about 20% (FeO4) and 80% (FeO6) polyhedra. It forms by rapid oxidation and hydrolysis, and exists in varying degrees of structure disorder; the two extremes are the so-called 2-line and 6-line ferrihydrites (distinguished by their X-ray powder diffraction patterns). It is a metastable nanomineral precursor to other minerals, e.g. hematite, goethite. There are no known deposits of ferrihydrite before the Pleistocene.
Two structure models have been proposed: the "f-phase" model and the "akdalaite" model; the first one seems to be correct (Paktunc et al., 2013).
Some lichen (e.g., Pertusaria corallina, Stereocaulon vulcani) may induce ferrihydrite formation on lava flows and basalt- and gabbro- hosted olivine and also on augite (see Burford et al., 2003).
The iron bacteria, especially Gallionella ferruginea, Leptothrix ochracea and Toxothrix trichogenes create ferrihydrite as a waste product of their metabolism.
A poorly crystalline nanomineral built up of about 20% (FeO4) and 80% (FeO6) polyhedra. It forms by rapid oxidation and hydrolysis, and exists in varying degrees of structure disorder; the two extremes are the so-called 2-line and 6-line ferrihydrites (distinguished by their X-ray powder diffraction patterns). It is a metastable nanomineral precursor to other minerals, e.g. hematite, goethite. There are no known deposits of ferrihydrite before the Pleistocene.
Two structure models have been proposed: the "f-phase" model and the "akdalaite" model; the first one seems to be correct (Paktunc et al., 2013).
Some lichen (e.g., Pertusaria corallina, Stereocaulon vulcani) may induce ferrihydrite formation on lava flows and basalt- and gabbro- hosted olivine and also on augite (see Burford et al., 2003).
The iron bacteria, especially Gallionella ferruginea, Leptothrix ochracea and Toxothrix trichogenes create ferrihydrite as a waste product of their metabolism.
Unique Identifiers
Mindat ID:
1493
Long-form identifier:
mindat:1:1:1493:5
Similar Names
| Ferrohydrite | A synonym of 'Limonite' |
IMA Classification of Ferrihydrite
Approved
Approval year:
1971
First published:
1973
Classification of Ferrihydrite
4.FE.35
4 : OXIDES (Hydroxides, V[5,6] vanadates, arsenites, antimonites, bismuthites, sulfites, selenites, tellurites, iodates)
F : Hydroxides (without V or U)
E : Hydroxides with OH, without H2O; sheets of edge-sharing octahedra
4 : OXIDES (Hydroxides, V[5,6] vanadates, arsenites, antimonites, bismuthites, sulfites, selenites, tellurites, iodates)
F : Hydroxides (without V or U)
E : Hydroxides with OH, without H2O; sheets of edge-sharing octahedra
4.3.2.2
4 : SIMPLE OXIDES
3 : A2X3
4 : SIMPLE OXIDES
3 : A2X3
7.20.9
7 : Oxides and Hydroxides
20 : Oxides of Fe
7 : Oxides and Hydroxides
20 : Oxides of Fe
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
Please only use the official IMA–CNMNC symbol. Older variants are listed for historical use only.
Please only use the official IMA–CNMNC symbol. Older variants are listed for historical use only.
| Symbol | Source | Reference for Standard |
|---|---|---|
| Fhy | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
| Fhy | Warr (2020) | Warr, L.N. (2020) Recommended abbreviations for the names of clay minerals and associated phases. Clay Minerals, 55, 261–264 doi:10.1180/clm.2020.30 |
Physical Properties of Ferrihydrite
Transparency:
Opaque
Colour:
Dark brown, yellow-brown
Streak:
Yellow-brown
Density:
3.96 g/cm3 (Measured)
Comment:
Synthesized material
Chemistry of Ferrihydrite
Mindat Formula:
Fe3+10O14(OH)2
Previously given as Fe3+5O3(OH)9.
Previously given as Fe3+5O3(OH)9.
Elements listed:
Crystallography of Ferrihydrite
Crystal System:
Trigonal
Cell Parameters:
a = 5.08 Å, c = 9.4 Å
Ratio:
a:c = 1 : 1.85
Unit Cell V:
210.08 ų (Calculated from Unit Cell)
Z:
1
Comment:
Point Group: n.d.; Space Group: n.d.
Crystal Structure
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File Best | x | y | z | a | b | c
CIF File Best | x | y | z | a | b | c
Rotation
Stop | Start
Stop | Start
Labels
Console Off | On | Grey | Yellow
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0012029 | Ferrihydrite | Jansen E, Kyek A, Schafer W, Schwertmann U (2002) The structure of six-line ferrihydrite Applied Physics A74 S1004-S1006 | 2002 | synthetic | 0 | 293 | |
| 0012028 | Ferrihydrite | Jansen E, Kyek A, Schafer W, Schwertmann U (2002) The structure of six-line ferrihydrite Applied Physics A74 S1004-S1006 | 2002 | synthetic | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder Diffraction
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 2.50 Å | (100) |
| 2.21 Å | (80) |
| 1.96 Å | (80) |
| 1.48 Å | (80) |
| 1.51 Å | (70) |
| 1.72 Å | (50) |
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| Stage 2: Planetesimal differentiation and alteration | 4.566-4.550 |
| 6 : Secondary asteroid phases | 4.566-4.560 |
| Stage 3b: Earth’s earliest hydrosphere | >4.45 |
| 14 : Hot springs, geysers, and other subaerial geothermal minerals | |
| Near-surface Processes | |
| 26 : Hadean detrital minerals | |
| Stage 5: Initiation of plate tectonics | <3.5-2.5 |
| 42 : Sea-floor Mn nodules | |
| Stage 7: Great Oxidation Event | <2.4 |
| 47a : [Near-surface hydration of prior minerals] | |
| 47h : [Near-surface oxidized, dehydrated minerals] | |
| 47i : [Terrestrial weathering of meteorites] | |
| Stage 10a: Neoproterozoic oxygenation/terrestrial biosphere | <0.6 |
| 48 : Soil leaching zone minerals | <0.6 |
| 49 : Oxic cellular biomineralization (see also #44) | <0.54 |
| Stage 10b: Anthropogenic minerals | <10 Ka |
| 55 : Anthropogenic mine minerals |
Geological Setting:
Cold-water springs, Mine workings, warm subsea springs, warm water seabed, thermal springs, thermal water in brooks, rivers and lakes.
Type Occurrence of Ferrihydrite
Co-Type Localities:
General Appearance of Type Material:
As poorly crystalline spheres, to 50 µm
Place of Conservation of Type Material:
Vernadsky Geological Musem, Moscow, 51508; A.E. Fersman Mineralogical Museum, Academy of Sciences, Moscow, Russia, 76642.
Associated Minerals at Type Locality:
Synonyms of Ferrihydrite
Other Language Names for Ferrihydrite
Varieties of Ferrihydrite
| Arsenical ferrihydrite | As-bearing variety. Relatively common as a weathering product of arsenopyrite. |
| Melanosiderite | Melanosiderite was described by Cooke (1875) as a hydrated basic ferric silicate. Examination of a specimen from the type locality and corresponding to the original description (BM66908), by energy-dispersive microanalysis, infrared spectroscopy, and X-ra... |
Relationship of Ferrihydrite to other Species
Member of:
Other Members of Nolanite Group:
Common Associates
Associations Based on Photo Data:
| 4 photos of Ferrihydrite associated with Goethite | Fe3+O(OH) |
| 3 photos of Ferrihydrite associated with Vivianite | Fe2+Fe2+2(PO4)2 · 8H2O |
| 2 photos of Ferrihydrite associated with Millerite | NiS |
| 1 photo of Ferrihydrite associated with Brochantite | Cu4(SO4)(OH)6 |
| 1 photo of Ferrihydrite associated with Feroxyhyte | Fe3+O(OH) |
| 1 photo of Ferrihydrite associated with 'Slag' | |
| 1 photo of Ferrihydrite associated with Quartz | SiO2 |
| 1 photo of Ferrihydrite associated with Fougèrite | Fe2+4Fe3+2(OH)12[CO3] · 3H2O |
| 1 photo of Ferrihydrite associated with Gypsum | CaSO4 · 2H2O |
| 1 photo of Ferrihydrite associated with Anglesite | PbSO4 |
Related Minerals - Strunz-mindat Grouping
| 4.FE. | Nannoniite | Al2(OH)5F |
| 4.FE.05 | Brucite | Mg(OH)2 |
| 4.FE.05 | Theophrastite | Ni(OH)2 |
| 4.FE.05 | Amakinite | Fe2+(OH)2 |
| 4.FE.05 | Portlandite | Ca(OH)2 |
| 4.FE.05 | Pyrochroite | Mn(OH)2 |
| 4.FE.10 | Doyleite | Al(OH)3 |
| 4.FE.10 | Bayerite | Al(OH)3 |
| 4.FE.10 | Nordstrandite | Al(OH)3 |
| 4.FE.10 | Gibbsite | Al(OH)3 |
| 4.FE.15 | Lepidocrocite | Fe3+O(OH) |
| 4.FE.15 | Böhmite | AlO(OH) |
| 4.FE.20 | Heterogenite | Co3+O(OH) |
| 4.FE.20 | Grimaldiite | CrO(OH) |
| 4.FE.25 | Lithiophorite | (Al,Li)MnO2(OH)2 |
| 4.FE.25 | Feitknechtite | Mn3+O(OH) |
| 4.FE.30 | Quenselite | PbMnO2(OH) |
| 4.FE.40 | Vernadite | (Mn4+,Fe3+,Ca,Na)(O,OH)2 · nH2O |
| 4.FE.40 | Feroxyhyte | Fe3+O(OH) |
| 4.FE.45 | Quetzalcoatlite | Zn6Cu3(TeO6)2(OH)6 · AgxPbyClx+2y |
| 4.FE.50 | Fuettererite | Pb3Cu2+6Te6+O6(OH)7Cl5 |
Other Information
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for Ferrihydrite
mindat.org URL:
https://www.mindat.org/min-1493.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
Mineral Dealers:
References for Ferrihydrite
Reference List:
Fleischer, Michael; Chao, G. Y.; Kato, Ikiro (1975) New Mineral Names. American Mineralogist, 60 (5-6). 485-489
Cardile, C. M. (1988) Tetrahedral Fe3+ in Ferrihydrite: 57Fe Mössbauer Spectroscopic Evidence. Clays and Clay Minerals, 36 (6). 537-539 doi:10.1346/ccmn.1988.0360607
Eggleton, Richard A. (1988) New Data and a Revised Structural Model for Ferrihydrite. Clays and Clay Minerals, 36 (2) 111-124 doi:10.1346/ccmn.1988.0360203
Manceau, A. (1990) New Data and a Revised Structural Model for Ferrihydrite: Comment. Clays and Clay Minerals, 38 (3) 331-334 doi:10.1346/ccmn.1990.0380314
Farmer, V. C. (1992) Possible confusion between so-called ferrihydrites and hisingerites. Clay Minerals, 27 (3) 373-378 doi:10.1180/claymin.1992.027.3.10
Waychunas, G.A., Fuller, C.C., Rea, B.A., Davis, J.A. (1996) Wide angle X-ray scattering (WAXS) study of “two-line” ferrihydrite structure: Effect of arsenate sorption and counterion variation and comparison with EXAFS results. Geochimica et Cosmochimica Acta, 60 (10) 1765-1781 doi:10.1016/0016-7037(96)89830-9
Rancourt, Denis G., Fortin, Danielle, Pichler, Thomas, Thibault, Pierre-Jean, Lamarche, Gilles, Morris, Richard V., Mercier, Patrick H.J. (2001) Mineralogy of a natural As-rich hydrous ferric oxide coprecipitate formed by mixing of hydrothermal fluid and seawater: Implications regarding surface complexation and color banding in ferrihydrite deposits. American Mineralogist, 86 (7) 834-851 doi:10.2138/am-2001-0707
Mazzetti, L., Thistlethwaite, P. J. (2002) Raman spectra and thermal transformations of ferrihydrite and schwertmannite. Journal of Raman Spectroscopy, 33 (2). 104-111 doi:10.1002/jrs.830
Roddick-Lanzilotta, Alisa J., McQuillan, A.James, Craw, Dave (2002) Infrared spectroscopic characterisation of arsenate (V) ion adsorption from mine waters, Macraes mine, New Zealand. Applied Geochemistry, 17 (4) 445-454 doi:10.1016/s0883-2927(01)00116-0
BURFORD, EUAN P., KIERANS, MARTIN, GADD, GEOFFREY M. (2003) Geomycology: fungi in mineral substrata. Mycologist, 17 (3). 98-107 doi:10.1017/s0269915x03003112
Frankel, R. B. (2003) Biologically Induced Mineralization by Bacteria. Reviews in Mineralogy and Geochemistry, 54 (1). 95-114 doi:10.2113/0540095
Hochella, M. F. (2005) Environmentally important, poorly crystalline Fe/Mn hydrous oxides: Ferrihydrite and a possibly new vernadite-like mineral from the Clark Fork River Superfund Complex. American Mineralogist, 90 (4) 718-724 doi:10.2138/am.2005.1591
Michel, F. M., Ehm, L., Antao, S. M., Lee, P. L., Chupas, P. J., Liu, G., Strongin, D. R., Schoonen, M. A. A., Phillips, B. L., Parise, J. B. (2007) The Structure of Ferrihydrite, a Nanocrystalline Material. Science, 316 (5832). 1726-1729 doi:10.1126/science.1142525
Berquó, Thelma S., Banerjee, Subir K., Ford, Robert G., Penn, R. Lee, Pichler, Thomas (2007) High crystallinity Si‐ferrihydrite: An insight into its Néel temperature and size dependence of magnetic properties. Journal of Geophysical Research: Solid Earth, 112 (B2). B02102 doi:10.1029/2006jb004583
Paktunc, Dogan, Dutrizac, John, Gertsman, Valery (2008) Synthesis and phase transformations involving scorodite, ferric arsenate and arsenical ferrihydrite: Implications for arsenic mobility. Geochimica et Cosmochimica Acta, 72 (11) 2649-2672 doi:10.1016/j.gca.2008.03.012
Paktunc, D., Manceau, A., Dutrizac, J. (2013) Incorporation of Ge in ferrihydrite: Implications for the structure of ferrihydrite. American Mineralogist, 98 (5) 848-858 doi:10.2138/am.2013.4312
Gilbert, B., Erbs, J. J., Penn, R. L., Petkov, V., Spagnoli, D., Waychunas, G. A. (2013) A disordered nanoparticle model for 6-line ferrihydrite. American Mineralogist, 98 (8) 1465-1476 doi:10.2138/am.2013.4421
Manceau, A., Skanthakumar, S., Soderholm, L. (2014) PDF analysis of ferrihydrite: Critical assessment of the under-constrained akdalaite model. American Mineralogist, 99 (1) 102-108 doi:10.2138/am.2014.4576
Sobron, P., Bishop, J. L., Blake, D. F., Chen, B., Rull, F. (2014) Natural Fe-bearing oxides and sulfates from the Rio Tinto Mars analog site: Critical assessment of VNIR reflectance spectroscopy, laser Raman spectroscopy, and XRD as mineral identification tools. American Mineralogist, 99 (7) 1199-1205 doi:10.2138/am.2014.4595
Paktunc, Dogan (2015) Phase Transformations In the System Fe–AsO4–SO4 and the Structure Of Amorphous Ferric Arsenate: Implications For Arsenic Stabilization In Mine Drainage and Industrial Effluents. The Canadian Mineralogist, 53 (5). 921-936 doi:10.3749/canmin.1500040
Grigg, Andrew R. C.; ThomasArrigo, Laurel K.; Schulz, Katrin; Rothwell, Katherine A.; Kaegi, Ralf; Kretzschmar, Ruben (2022) Ferrihydrite transformations in flooded paddy soils: rates, pathways, and product spatial distributions. Environmental Science: Processes & Impacts, 24 (10). 1867-1882 doi:10.1039/d2em00290f
Localities for Ferrihydrite
Showing 147 localities.
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
Algeria | |
| Greshake (1997) +1 other reference |
Antarctica | |
| Ling et al. (2015) |
| Fernandes et al. (2025) |
| Barczuk A. & Tatur A. 2003: BIOGENIC ... |
| Cui et al. (2023) |
| Barczuk et al. (2003) | |
Arctic Ocean | |
| Murdmaa et al. (2000) | |
| Sahlström et al. (2022) |
Atlantic Ocean | |
| Dekov et al. (2010) | |
| Bogdanov et al. (2008) |
| Bogdanov et al. (2008) | |
| Sergienko et al. (2024) | |
| Lartaud et al. (2011) |
| Bogdanov et al. (2008) |
| Bogdanov et al. (2008) | |
| Bogdanov et al. (2008) | |
Australia | |
| McQueen +2 other references |
| Parbhakar-Fox (2016) |
| Parbhakar-Fox (2016) | |
| D. J. Barber & R. Hutchinson (1991) |
Austria | |
| Schnorrer et al. (2002) |
Brazil | |
| Spier et al. (2008) |
| Waber (1991) |
| Santos et al. (2025) |
Bulgaria | |
| Tarassov et al. (2018) |
Canada | |
| Moncur et al. (2015) |
| Battler et al. (2013) |
| Izawa et al. (2011) |
China | |
| Zhiwei Bao (2001) |
| Zhian Qin (1999) |
| |
| |
Czech Republic | |
| RÜSENBERG et al. (1996) |
| Matýsek et al. (2023) |
| Jirásek et al. (2019) |
| Matýsek et al. (2022) |
Egypt | |
| Treiman et al. (1991) |
| Fleischer M (1973) | |
Eurasian Plate | |
| Wang et al. (2025) |
Finland | |
| Schwertmann (1987) |
| Schwertmann (1987) |
| Parviainen et al. (2012) |
France | |
| Keller et al. (1990) |
| Cano et al. (2025) |
| Gautier et al. (2006) |
| Lheur et al. (1998) |
| Tomeoka et al. (1988) +1 other reference |
Germany | |
| Walenta (1992) |
| Nieding (1990) |
| Dill et al. (2008) |
| Gröbner et al. (2011) |
| |
| Pawlowski (1991) |
| Bender et al. (1994) |
| Joan Rosell. RosellMinerals |
| Lapis 30 (7/8) |
| Weiß (1990) |
Greece | |
| Gelaude et al. (1996) |
| Gelaude et al. (1996) |
| Schnorrer-Köhler et al. (1988) | |
| Gelaude et al. (1996) |
| Gelaude et al. (1996) |
| Gelaude et al. (1996) | |
| Kanellopoulos et al. (2018) |
| Tsirigoti et al. (2025) |
| Altherr et al. (2013) |
| Fleischer M (1973) |
Hungary | |
| Bujtor et al. (2024) |
India | |
| Berlin et al. (2007) |
Indian Ocean | |
| Hou et al. (2024) |
| Maciąg et al. (2019) | |
| Linsy et al. (2023) |
Indonesia | |
| Dani Lukman Hakim (2016) |
Italy | |
| Lee et al. (1996) +2 other references |
| E. Dinelli (1998) +2 other references |
| Nevini et al. (2002) +1 other reference |
| Ko Jansen |
| Muenchener Micromounter-Lithothek |
| Menchetti et al. (2015) |
Japan | |
| Tazaki (2000) |
| Kato +6 other references |
Kazakhstan | |
| Pekov (1998) |
| KAZ Minerals |
| Pekov (1998) |
| Pekov (1998) |
Mexico | |
| Canet et al. (2005) |
| Minera Autlan |
Nazca Plate | |
| Zawadzki et al. (2022) | |
New Zealand | |
| Haffert et al. (2010) |
| Haffert et al. (2010) |
| Haffert et al. (2010) | |
| Haffert et al. (2010) |
| Haffert et al. (2010) |
Norway | |
| Segalstad (2004) |
Pacific Ocean | |
| Glasby et al. (2006) |
| Novikov et al. (2006) |
| Peretyazhko et al. (2025) |
| Peretyazhko et al. (2025) | |
| Schwarz-Schampera et al. (2007) |
| Schwarz-Schampera et al. (2007) | |
| Novikov et al. (2006) |
Papua New Guinea | |
| Moss et al. (2001) |
| R Moss 2000. GEOCHEMISTRY AND ... | |
| Pichler et al. (1999) |
Poland | |
| Musiał J. 1996: Results of preliminary ... |
| Mateusz Dulski et al. (2018) +1 other reference |
| Siuda (2001) |
| Siuda (2004) |
| Nejbert et al. (2013) |
| Cabała +4 other references |
Portugal | |
| De los Ríos et al. (2011) |
Red Sea | |
| Parnell +2 other references | |
Russia | |
| Sharygin +9 other references |
| Pavel M. Kartashov (n.d.) | |
| Goryunov et al. (2023) |
| Goryunov et al. (2023) | |
| Petrov (2005) |
Saudi Arabia | |
| Surour (2015) |
Slovakia | |
| Majzlan J. et al. (2006) |
Spain | |
| Navarro et al. (2008) |
| Navarro et al. (2008) | |
| Pascual +1 other reference |
Sweden | |
| Taddei et al. (2025) |
Turkey | |
| Goryunov et al. (2023) |
Turkmenistan | |
| Fleischer M (1973) |
| Lebedev et al. (1983) | |
UK | |
| Jarvis |
| Norman Wilson personal collection |
USA | |
| Langman et al. (2026) |
| Eckel et al. (1997) |
| EDX Analysis (02/12/2022) |
| Treiman et al. (1993) |
| www.lpi.usra.edu (n.d.) |
| O.P. Bricker et al. (2004) |
| Cerato |
| Gnanou (2018) |
| Gnanou (2018) | |
| Gnanou (2018) |
| New Mexico Geological Society Guidebook +1 other reference |
| Borden et al. (2008) |
| U.S. Geological Survey/ U.s. Department ... |
| [var: Melanosiderite] Gordon (1922) |
| William B. White – Cave sediments and ... |
| Hammarstrom et al. (1999) |
162173 Ryugu | |
Quick NavTopAbout FerrihydriteUnique IdentifiersSimilar NamesIMA Classification Classification Mineral SymbolsPhysical Properties Chemistry Crystallography Crystal StructureX-Ray Powder DiffractionGeological EnvironmentType Occurrence SynonymsOther LanguagesVarietiesRelationshipsCommon AssociatesStrunz-MindatOther InformationInternet Links References Localities Locality List
Clara Mine, Oberwolfach, Ortenaukreis, Freiburg Region, Baden-Württemberg, Germany
