Satpaevite
A valid IMA mineral species
This page is currently not sponsored. Click here to sponsor this page.
About Satpaevite
Kanysh Imantaevich Satpaev (1899 - 1964)
Formula:
Al12V4+2V5+6O37 · 30H2O
Colour:
Saffron-yellow to greenish yellow
Lustre:
Pearly, Dull
Hardness:
1½
Specific Gravity:
2.4
Crystal System:
Orthorhombic
Name:
Named after Kanysh Imantaevich Satpaev (April 11, 1899 – January 31, 1964) geologist, Institute of Geological Sciences, Kazakhstan.
This page provides mineralogical data about Satpaevite.
Unique Identifiers
Mindat ID:
3542
Long-form identifier:
mindat:1:1:3542:8
IMA Classification of Satpaevite
Approved
IMA Formula:
Al12(V4+,V5+)8O37 · 30H2O (?)
First published:
1959
Classification of Satpaevite
4.HG.65
4 : OXIDES (Hydroxides, V[5,6] vanadates, arsenites, antimonites, bismuthites, sulfites, selenites, tellurites, iodates)
H : V[5,6] Vanadates
G : Unclassified V oxides
4 : OXIDES (Hydroxides, V[5,6] vanadates, arsenites, antimonites, bismuthites, sulfites, selenites, tellurites, iodates)
H : V[5,6] Vanadates
G : Unclassified V oxides
47.4.1.1
47 : VANADIUM OXYSALTS
4 : Vanadium Bronzes
47 : VANADIUM OXYSALTS
4 : Vanadium Bronzes
21.3.5
21 : Vanadates (and vanadates with arsenate or phosphate)
3 : Vanadates of Al, rare earths, Pb, V or Bi
21 : Vanadates (and vanadates with arsenate or phosphate)
3 : Vanadates of Al, rare earths, Pb, V or Bi
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference |
|---|---|---|
| Spv | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Physical Properties of Satpaevite
Pearly, Dull
Comment:
Pearly on the cleavage; dull when fine-grained
Colour:
Saffron-yellow to greenish yellow
Hardness:
1½ on Mohs scale
Cleavage:
Perfect
One direction, perfect, pinacoidal.
One direction, perfect, pinacoidal.
Density:
2.4 g/cm3 (Measured)
Optical Data of Satpaevite
Type:
Biaxial (+)
RI values:
nα = 1.676 nβ = 1.681 nγ = 1.69
2V:
Measured: 70° , Calculated: 74°
Max. Birefringence:
δ = 0.014
Based on recorded range of RI values above.
Based on recorded range of RI values above.
Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
Surface Relief:
Moderate
Dispersion:
r > v strong
Optical Extinction:
Parallel extinction.
Pleochroism:
Weak
Comments:
In transmitted light: greenish yellow to pale olive.
Absorption: Z > X.
Absorption: Z > X.
Chemistry of Satpaevite
Mindat Formula:
Al12V4+2V5+6O37 · 30H2O
Element Weights:
Elements listed:
Crystallography of Satpaevite
Crystal System:
Orthorhombic
Comment:
Questionable
X-Ray Powder Diffraction
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 1.918 Å | (100) |
| 2.330 Å | (90) |
| 1.471 Å | (80) |
| 3.905 Å | (70) |
| 5.86 Å | (60) |
| 1.554 Å | (50) |
| 4.425 Å | (40) |
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| Stage 7: Great Oxidation Event | <2.4 |
| 47a : [Near-surface hydration of prior minerals] | |
| 47e : [Vanadates, chromates, manganates] | |
| 47h : [Near-surface oxidized, dehydrated minerals] |
Type Occurrence of Satpaevite
Co-Type Localities:
General Appearance of Type Material:
Crystals, to 0.1 mm, platy with hexagonal to rounded outlines, in fine granular aggregates, may be foliated.
Place of Conservation of Type Material:
Mining Institute, St. Petersburg, 1251/1; Vernadsky Geological Museum, Moscow, 49850; A.E. Fersman Mineralogical Museum, Academy of Sciences, Moscow, Russia, 62760.
Geological Setting of Type Material:
In the oxidation zone of a vanadiferous clay-anthraxolite deposit.
Associated Minerals at Type Locality:
Other Language Names for Satpaevite
Common Associates
Related Minerals - Strunz-mindat Grouping
| 4.HG. | Calciodelrioite | Ca(VO3)2 · 4H2O |
| 4.HG. | Trebiskyite | Na3Mg2[TiV9O28] · 22H2O |
| 4.HG. | Cadvanite | Cd(VO3)2 |
| 4.HG.05 | Fervanite | Fe3+4V5+4O16 · 5H2O |
| 4.HG.10 | Huemulite | Na4Mg(V10O28) · 24H2O |
| 4.HG.15 | Vanalite | NaAl9V12O42(OH)4 · 33H2O |
| 4.HG.20 | Simplotite | CaV4+4O9 · 5H2O |
| 4.HG.25 | Vanoxite | V4+4V5+2O13 · 8H2O |
| 4.HG.30 | Navajoite | Fe3+V5+9O24 · 12H2O |
| 4.HG.35 | Delrioite | Sr(VO3)2 · 4H2O |
| 4.HG.40 | Metadelrioite | CaSr(V2O6)(OH)2 |
| 4.HG.45 | Barnesite | (Na,Ca)V6O16 · 3H2O |
| 4.HG.50 | Hendersonite | (Ca,Sr)1.3V6O16 · 6H2O |
| 4.HG.55 | Grantsite | (Na,Ca)2+x(V5+,V4+)6O16 · 4H2O |
| 4.HG.60 | Lenoblite | V4+2O4 · 2H2O |
| 4.HG.70 | Pandoraite-Ba | BaV4+5V5+2O16 · 3H2O |
| 4.HG.70 | Pandoraite-Ca | CaV4+5V5+2O16 · 3H2O |
Other Information
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for Satpaevite
mindat.org URL:
https://www.mindat.org/min-3542.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
References for Satpaevite
Reference List:
Localities for Satpaevite
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
Kazakhstan (TL) | |
| Ankinovich (1959) +2 other references |
| Amer.Mineral. (1961) |
| ZVMO (1959) +2 other references |
Quick NavTopAbout SatpaeviteUnique IdentifiersIMA Classification Classification Mineral SymbolsPhysical Properties Optical Data Chemistry Crystallography X-Ray Powder DiffractionGeological EnvironmentType Occurrence Other LanguagesCommon AssociatesStrunz-MindatOther InformationInternet Links References Localities Locality List
Kurumsak V Deposit, Aksumbe, Sozak District, Turkistan Region, Kazakhstan
