Kaatialaite
A valid IMA mineral species
This page is currently not sponsored. Click here to sponsor this page.
About Kaatialaite
There are lots of stones in Kaatiala to study
Kaatiala pegmatite, Kuortane, South Ostrobothnia, Finland
Kaatiala pegmatite, Kuortane, South Ostrobothnia, Finland
Formula:
Fe3+[AsO2(OH)2]3 · 5H2O
The water content appears to be variable (Raade et al., 1984); the synthetic compound has 5H2O.
Colour:
Pale grey, pale yellow, white, pale blue, greenish blue
Lustre:
Earthy
Specific Gravity:
2.64
Crystal System:
Monoclinic
Name:
Named by G. Raade, M.H. Mladeck, R. Kristiansen, and V.K. Din in 1984 for the type locality of Kaatiala pegmatite, Finland.
Type Locality:
Unique Identifiers
Mindat ID:
2126
Long-form identifier:
mindat:1:1:2126:1
IMA Classification of Kaatialaite
Approved
First published:
1984
Classification of Kaatialaite
8.CC.10
8 : PHOSPHATES, ARSENATES, VANADATES
C : Phosphates without additional anions, with H2O
C : With only medium-sized cations, RO4:H2O = 1:1.5
8 : PHOSPHATES, ARSENATES, VANADATES
C : Phosphates without additional anions, with H2O
C : With only medium-sized cations, RO4:H2O = 1:1.5
39.3.9.1
39 : HYDRATED ACID PHOSPHATES,ARSENATES AND VANADATES
3 : Miscellaneous
39 : HYDRATED ACID PHOSPHATES,ARSENATES AND VANADATES
3 : Miscellaneous
20.9.5
20 : Arsenates (also arsenates with phosphate, but without other anions)
9 : Arsenates of Fe
20 : Arsenates (also arsenates with phosphate, but without other anions)
9 : Arsenates of Fe
Mineral Symbols
As of 2021 there are now IMA–CNMNC approved mineral symbols (abbreviations) for each mineral species, useful for tables and diagrams.
| Symbol | Source | Reference |
|---|---|---|
| Kaa | IMA–CNMNC | Warr, L.N. (2021). IMA–CNMNC approved mineral symbols. Mineralogical Magazine, 85(3), 291-320. doi:10.1180/mgm.2021.43 |
Physical Properties of Kaatialaite
Earthy
Transparency:
Translucent
Colour:
Pale grey, pale yellow, white, pale blue, greenish blue
Density:
2.64 g/cm3 (Measured) 2.64 g/cm3 (Calculated)
Comment:
Measured was with synthetic material
Optical Data of Kaatialaite
Type:
Biaxial (+)
RI values:
nα = 1.573 nβ = 1.574 nγ = 1.636
2V:
Measured: 15° , Calculated: 16°
Max. Birefringence:
δ = 0.063
Based on recorded range of RI values above.
Based on recorded range of RI values above.
Interference Colours:
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
The colours simulate birefringence patterns seen in thin section under crossed polars. They do not take into account mineral colouration or opacity.
Michel-Levy Bar The default colours simulate the birefringence range for a 30 µm thin-section thickness. Adjust the slider to simulate a different thickness.
Grain Simulation You can rotate the grain simulation to show how this range might look as you rotated a sample under crossed polars.
Surface Relief:
Moderate
Dispersion:
none
Chemistry of Kaatialaite
Mindat Formula:
Fe3+[AsO2(OH)2]3 · 5H2O
The water content appears to be variable (Raade et al., 1984); the synthetic compound has 5H2O.
The water content appears to be variable (Raade et al., 1984); the synthetic compound has 5H2O.
Element Weights:
Elements listed:
Crystallography of Kaatialaite
Crystal System:
Monoclinic
Class (H-M):
2/m - Prismatic
Cell Parameters:
a = 15.25 Å, b = 19.60 Å, c = 4.72 Å
β = 91.8°
β = 91.8°
Ratio:
a:b:c = 0.778 : 1 : 0.241
Unit Cell V:
1,410.11 ų (Calculated from Unit Cell)
Morphology:
Acicular; powder coatings.
Comment:
Space group (P21/n) and cell data for synthetic material (Boudjada & Guitel, 1981). Raade et al. (1984) suggest space group P21 or P21/m. Water content appears to vary, and therefore also unit-cell parameters (Raade et al., 1984).
Crystal Structure
Load
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Unit Cell | Unit Cell Packed
2x2x2 | 3x3x3 | 4x4x4
Show
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Big Balls | Small Balls | Just Balls | Spacefill
Polyhedra Off | Si Polyhedra | All Polyhedra
Remove metal-metal sticks
Display Options
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
Black Background | White Background
Perspective On | Perspective Off
2D | Stereo | Red-Blue | Red-Cyan
View
CIF File Best | x | y | z | a | b | c
CIF File Best | x | y | z | a | b | c
Rotation
Stop | Start
Stop | Start
Labels
Console Off | On | Grey | Yellow
Console Off | On | Grey | Yellow
Data courtesy of the American Mineralogist Crystal Structure Database. Click on an AMCSD ID to view structure
| ID | Species | Reference | Link | Year | Locality | Pressure (GPa) | Temp (K) |
|---|---|---|---|---|---|---|---|
| 0009745 | Kaatialaite | Boudjada A, Guitel J C (1981) Structure cristalline d'un orthoarseniate acide de fer(III) pentahydrate: Fe(H2AsO4)3*5H2O Acta Crystallographica B37 1402-1405 |  | 1981 | synthetic | 0 | 293 |
CIF Raw Data - click here to close
X-Ray Powder Diffraction
Powder Diffraction Data:
| d-spacing | Intensity |
|---|---|
| 12.2 Å | (30) |
| 9.95 Å | (90) |
| 8.35 Å | (100) |
| 7.69 Å | (90) |
| 7.17 Å | (10) |
| 6.07 Å | (80) |
| 5.01 Å | (10) |
| 4.96 Å | (30) |
| 4.72 Å | (40) |
| 4.62 Å | (10) |
| 4.58 Å | (10) |
| 4.50 Å | (60) |
| 4.48 Å | (60) |
| 4.38 Å | (20) |
| 4.28 Å | (40) |
| 4.17 Å | (10) |
| 4.09 Å | (10) |
| 4.05 Å | (40) |
| 3.83 Å | (70) |
| 3.77 Å | (80) |
| 3.69 Å | (10) |
| 3.57 Å | (30) |
| 3.55 Å | (30) |
| 3.53 Å | (60) |
| 3.52 Å | (60) |
Comments:
ICDD (synthetic)
Geological Environment
Paragenetic Mode(s):
| Paragenetic Mode | Earliest Age (Ga) |
|---|---|
| Stage 7: Great Oxidation Event | <2.4 |
| 47a : [Near-surface hydration of prior minerals] | |
| 47d : [Arsenates, antimonates, selenates, bismuthinates] |
Type Occurrence of Kaatialaite
General Appearance of Type Material:
Acicular aggregates and powdery coatings on löllingite.
Place of Conservation of Type Material:
Mineralogical-Geological Museum, University of Oslo, Oslo, Norway.
The Natural History Museum, London, England.
The Natural History Museum, London, England.
Geological Setting of Type Material:
Granite pegmatite
Associated Minerals at Type Locality:
Synonyms of Kaatialaite
Other Language Names for Kaatialaite
Common Associates
Associated Minerals Based on Photo Data:
| 15 photos of Kaatialaite associated with Claudetite | As2O3 |
| 11 photos of Kaatialaite associated with Native Arsenic | As |
| 9 photos of Kaatialaite associated with Arsenolite | As2O3 |
| 5 photos of Kaatialaite associated with Skutterudite | CoAs3 |
| 4 photos of Kaatialaite associated with Scorodite | Fe3+AsO4 · 2H2O |
| 3 photos of Kaatialaite associated with Proustite | Ag3AsS3 |
| 2 photos of Kaatialaite associated with Safflorite | (Co,Ni,Fe)As2 |
| 1 photo of Kaatialaite associated with Argentopyrite | AgFe2S3 |
| 1 photo of Kaatialaite associated with Quartz | SiO2 |
Related Minerals - Strunz-mindat Grouping
| 8.CC. | Correianevesite | Fe2+Mn2+2(PO4)2 · 3H2O |
| 8.CC.05 | Landesite | Mn2+3-xFe3+x(PO4)2(OH)x · (3-x)H2O |
| 8.CC.05 | Reddingite | (Mn2+,Fe2+)3(PO4)2 · 3H2O |
| 8.CC.05 | Garyansellite | Mg2Fe3+(PO4)2(OH) · 2H2O |
| 8.CC.05 | Phosphoferrite | (Fe2+,Mn2+)3(PO4)2 · 3H2O |
| 8.CC.05 | Kryzhanovskite | (Fe3+,Mn2+)3(PO4)2(OH,H2O)3 |
| 8.CC.15 | Leogangite | Cu10(AsO4)4(SO4)(OH)6 · 8H2O |
Other Information
Health Risks:
No information on health risks for this material has been entered into the database. You should always treat mineral specimens with care.
Internet Links for Kaatialaite
mindat.org URL:
https://www.mindat.org/min-2126.html
Please feel free to link to this page.
Please feel free to link to this page.
Search Engines:
External Links:
References for Kaatialaite
Reference List:
Raade, Gunnar, Mladeck, Micael H., Kristiansen, Roy, Din, Victor K. (1984) Kaatialaite, a new ferric arsenate mineral from Finland. American Mineralogist, 69 (3-4) 383-387
Localities for Kaatialaite
symbol to view information about a locality.
The Locality List
- This locality has map coordinates listed.
- This locality has estimated coordinates.
ⓘ - Click for references and further information on this occurrence.
? - Indicates mineral may be doubtful at this locality.
- Good crystals or important locality for species.
- World class for species or very significant.
(TL) - Type Locality for a valid mineral species.
(FRL) - First Recorded Locality for everything else (eg varieties).
All localities listed without proper references should be considered as questionable.
Czech Republic | |
| Lapis 2002 (7/8) |
| 86. +1 other reference | |
| Plašil J et al. (2006) |
| Filippi (2004) |
Finland (TL) | |
| Raade et al. (1984) |
France | |
| SARP et al. (2002) |
| Favreau et al. (2024) |
| Georges FAVREAU collection & EDX ... +1 other reference | |
Germany | |
| |
| |
| Walenta (1987) +1 other reference | |
| Lorenz (2004) |
| Schmetzer et al. (1986) |
| SEM-EDS and XRD by Joy Desor and ... |
| Wittern (2001) |
| Lapis 1994 (10) |
Greece | |
| Rieck et al. (2018) |
| no description given yet] +1 other reference | |
Italy | |
| Marco Bonifazi collection |
Spain | |
| Kankita y Kaatialaita de las Minas de Varilongo (Santa Comba, La Coruña, España) |
USA | |
| Cesbron et al. (1992) |
